| Specifications | X6336 |
| Table size | 1320x360mm |
| T slot | 3 |
| Size (Width) | 18mm |
| Centre distance | 80mm |
| Max. load of table | 300kg |
| Table longitudinal travel (manual/auto) | 1000mm |
| Table cross travel (manual/auto) | 300mm |
| Table vertical travel (manual/auto) | 450mm |
| Spindle taper | ISO40(V)ISO50(H) |
| Spindle speed/step--Vertical | 70-3620rpm/10steps |
| Spindle speed/step--Horizontal | 58-1800rpm/12steps |
| Max.drilling dia. | 30mm |
| Max. end milling width | 125mm |
| Max. vertical milling dia. | 25mm |
| Max. tapping dia. | 16mm |
| Quill travel | 140mm |
| Swivel angle of headstock | ±45º |
| Vertical spindle axis to column surface | 150-550mm |
| Vertical spindle nose to table surface | 200-650mm |
| Horizontal spindle axis to table surface | 0-450mm |
| Horizontal spindle axis to arm bottom | 235mm |
| Arm travel | 400mm |
| Longitudinal/cross feed | 15-370mm/min/8steps |
| Vertical/step | 575mm/min/1step |
| Longitudinal/cross rapid speed | 575mm/min |
| Rapid traverse vertical | 575mm/min |
| Automatic spindle feed | 0.04/0.08/0.15mm/rev (3steps) |
| Main motor | 3.7kw(V),4.0kw(H) |
| (X/Y/Z) feed motor | 0.75kw(X/Y)/1.1kw(Z) |
| Coolant motor | 0.09kw |
| Packing size | 193x185x225cm |
| N.W/G.W | 2200/2400kg |
