Modern Pig Farm Steel Building/ Poultry House/Pig House

US$29.00-89.00 200 Square Meters (MOQ)

Basic Info.

Model NO.
KXD-PPH1201
Power Source
Electric
Heating and Ventilation Equipment Type
Air Duct
Epidemic Prevention Equipment
Mobile Vaccination Car
Blade Type
Straight Teeth
Computerized
Computerized
Certification
QS, GMP, ISO9001:2008, CE
Condition
New
Material
Galvanized Steel
Auto Manure Cleaning
Manure Channel, Slatted Plastic Floor, Autoscraper
Fog Spray System
Available
Product Name
Automatic Broiler Chicken Equipmen
Transport Package
40 Feet Container
Trademark
KXD-PPH1201
Origin
Qingdao
Production Capacity
50000

Product Description


Product Description
Items Specification
Main Steel Frame Column Q235, Q345 Welded H Section Steel
Beam Q235, Q345 Welded H Section Steel
Secondary Frame Purlin Q235 C and Z purlin
Knee brace Q235 Angle Steel
Tie Rod Q235 Circular Steel Pipe
Brace Q235 Round Bar
Vertical and Horizontal Support Q235 Angle Steel, Round Bar or Steel Pipe
Maintenance system Roof Panel EPS Sandwich Panel / Glass Fiber Sandwich Panel / Rock Wool Sandwich Panel / Pu Sandwich Panel /Steel Sheet
Wall Panel Sandwich Panel / Corrugated Steel Sheet
Accessories Window Aluminiumn Alloy Window / PVC Window / Sandwich Panel Window
Door Sliding Sandwich Panel Door / Rolling Metal Door / Personal Door
Rainspout PVC
Live load on Roof In 120kg/Sqm (Color steel panel surrounded)
Wind Resistance Grade 12 Grades
Earthquake-resistance 8 Grades
Structure Usage Up to 20 years
Finishing Options Vast array of colors and textures available
Paint Options Alkyd paiting, two primary painting, two finish painting (gray paint, red paint, white paint, epoxy zinc etc.) Or Galvanized.


Product Details
Item Specification
Size 2400*650*1100mm and customized sizes
PVC Fence 500*35mm
Farrowing stall Steel pipe 1" &3/4", wholly hot galvanized
Floor system Cast iron floor&hot galvanized floor for sow& plastic floor for piglets
Floor beam Carbon steel beam for sow, FRP beam for piglets
Sow feeder SS304
Drinking system Nipple drinker for sow, drinking bowl for piglets
Optional items Feeder for piglet, heating system, rubber mat etc.

Packaging & Shipping
FAQ
Q1: What are your main products?
A: Our main products are divided into 2 parts, Steel Structure Building and Poultry Equipment.
Steel Structure Building: Workshop, Warehouse, Factory, Exhibition Hall, Profabricated Poultry House, Steel Structure Frame and Container House, etc.
Poultry Equipment for Chicken(Layer, Broiler, Breeder, Pullet), Duck, Pig, Goat, Rabbit, Quail, Pigeon, Cattle, etc.
All products can be customized as your demand.
Q2: What information should I provide before quotation?
A:
1 Location (Where the poultry house will be built?) _____country, area
Or Local Climate: Extreme Temperature _____Lowest_____Highest
2 House Size(for equipment arrangement): Length*Width*Height _____mm*_____mm*_____mm
Or Breeding Quantity: _____Chicken & Breeding density _____unit/m2
3 Voltage_____V, Power: single-phase or three-phase, _____Herz
4 Any other special requests.

Q3: What kind drawing will you provide?
A: Plan Drawing, Elevation Drawing, Sectional Drawing, Foundation Drawing and Installation Drawing.

If you are interested in us, please kindly find the dimensions needed for poultry equipment(Q2) for your reference. Our team will provide the best layout as your demand.
Please feel free to contact Ferchichi for more information thank you .
