Lowbed semi-trailers are usually used to transport heavy-duty vehicles (such as tractors, buses, special-purpose vehicles, etc.), rail vehicles, mining machinery, forestry machinery, construction machinery (such as excavators, bulldozers, loaders, pavers, cranes, etc.) and other heavy-loaded goods. The lower the center of gravity, the better the stability and safety, and the stronger the ability to transport extra-high cargo and pass overhead obstacles.
Appearance Features:
1.Product name: Three-line six-axis low-bed semi-trailer
2.Dimensions: 13000*3000*3100
3.Vehicle length: 13meters
4.Design load: 27.1 tons
Chassis:
1.Tire: 235/75R 17.5 DOUBLE COIN/24
2.Axle: 70-ton light York
3.Outrigger: 28T small stroke
4.Steel Ring: 17.5*6.75/24
5.ABS:NONE
6.Leaf spring: NONE
7.Self Weight:9.9T
Product features: 1. Adopt the most advanced "topology optimization" analysis method and manufacturing process in the world, and key parts adopt "double-head automatic tracking submerged arc welding" and "CNC plasma cutting machine"
2. "Edge cleaning machine" and other automated machines. Through continuous and reasonable optimization of product structure, the product has the following features: light weight, large load capacity, no uneven wear of tires, no tire bite, etc., effectively combining the current national relaxed environment for large-scale transportation.
Product parameters:
| type | 13m three-lane six-axle high-strength steel low-bed semi-trailer | 13m low bed semi-trailer | 13m low bed semi-trailer (rated load 26 tons) |
| Basic Information |
|
|
|
| Length | 13M | 13M | 13M |
| Width | 3M | 3M | 3M |
| Height | 3.1M | 3.1M | 3.1M |
| Vehicle weight | 12.9T | 10.51T | 8.79T |
| Desigh Load | 27.1T | 30.3T | 26T |
| Chassis parameters |
|
|
|
| Axle brand | 70-ton light York |
|
|
| Number of axles | 6 | 3 | 2 |
| Axle load | 8000/8000/8000(3 lines and six axle) | -23990(3 Axle Group) |
|
| Number of wheels | 24 | 12 | 8 |
| Tire |
|
|
|
| Tire Brand | Double Coin |
|
|
| Tire Specifications | 235/75R17.5 | 8.25R20(14PR,16PR),8.25-20 16PR | 8.25R20 16PR |
| Number of Tires | 24 | 12 | 8 |
| Accessories |
|
|
|
| Outrigger | 28T small stroke |
|
|
| ABS |
| Bachak | Kemi |
>>
