Low Price High Efficiency Independently Operated Small Volume Array Rotary Evaporator

Product Description

Array rotary evaporator is an innovative pre-processing equipment that can simultaneously concentrate and process multiple samples. It consists of multiple miniRotar rotary evaporator units, a vacuum system, and a solvent condensation recovery system. It can greatly improve the experiment while realizing multiple sample processing. Room space utilization. The miniRotars can work simultaneously, or operate independently. Each can set it's own temperature, adjust speed, release vacuum etc., without interfering other rotary evaporator units.
Extreme mini -- Saves Space ○ MiniRotar designs longitudinal rotating axis innovatively, reducing the product width to 25cm,which is one third of traditional rotary evaporator. 1.8m standard fume hood can put up to 5 miniRotars, fully save the fume hood space. Array Combination -- Improves Efficiency ○ Special connector design can keep multiple units working in parallel, sharing one Vacuum system and one Recovery system. Highly recommended on processing multiple samples at the same time to improve work efficiency.○ Each miniRotar can set it's own temperature, rotation speed and time, and can independently lift and lower the flask. MiniRotar 500s equips an independent quick release vacuum button, which can release the vacuum independently without interfering other rotary evaporator units. Timing of evaporation -- Less Attention ○ MiniRotar500s can setting it's working time according to users experience. Once time is up, miniRotar500s will automatically stop rotating and release vacuum, lift the flask to part from water bath, and automatically stop sample evaporation and concentration.
Double Protection -- Avoid Contamination ○ MiniRotar is equipped with a backflow prevention connector, which can avoid contamination of samples and ensure the accuracy of analysis results. Rotary evaporator

Technical parameter	miniRotar500	miniRotar500s
Heating temperature range	Room temperature~95ºC	Room temperature~95ºC
Temperature control accuracy	±1ºC	±1ºC
Temperature setting and display	Knob to quickly set the target temperature and real-time temperature digital display	Knob to quickly set the target temperature and real-time temperature digital display
Dry burn protection mode	Automatic power off for dry burning	Automatic power off for dry burning
heating method	Concealed heating	Concealed heating
Rotation axis direction	Portrait setting	Portrait setting
Rotation parameter setting and display	TFT4.3Inch touch LCD screen	TFT4.3Inch touch LCD screen
Rotating screen lifting mode	Manual and automatic dual mode	Manual and automatic dual mode
Timing function	N/A	YES
		(The time can be set within 0-999min. When the time is reached, the rotating bottle stops rotating.
		Automatically lift out of the heating water bath and release the vacuum at the same time, the sample stops evaporating)
Maximum volume of rotating bottle	500mL	500mL
Rotating bottle interface specifications	standard 24/29 interface	standard 24/29 interface
Rotation mode	clockwise rotation	Three modes: clockwise counterclockwise clockwise and counterclockwise alternately
Vacuum release method	Manual switch valve to release vacuum	Shortcut button to release vacuum
		(When multiple groups are used in parallel, the vacuum of one group of rotary evaporators is released without affecting the normal operation of other rotary evaporators)
Turn off the power and automatically release the vacuum	N/A	YES
Sample observation light	USB interface led light	USB interface led light
Suction port	φ10mm Pagoda connector	φ10mm Pagoda connector
Communication Interface	N/A	RS485
voltage	AC220V 50/60Hz	AC220V 50/60Hz
input power	700W	700W
Dimensions(mm)	deep 530×width 250×high 520

Vacuum pump

Technical parameter	eV35	eV35s
Vacuum pump type	High performance diaphragm vacuum pump	German original diaphragm vacuum pump
Diaphragm material	PTFE	PTFE
Pump head material	PTFE	PTFE
Ultimate vacuum	8mbar	8mbar
Maximum pumping speed	35L/min	34L/min
Pneumatic interface	φ10mm Pagoda connector	φ10mm Pagoda connector
Vacuum gauge	Pointer vacuum gauge	Pointer vacuum gauge
Vacuum control valve	Precision hand-tightened vacuum control valve	Precision hand-tightened vacuum control valve
Vacuum adjustment range	-0.1-0Mpa	-0.1-0Mpa
voltage	AC220V 50/60Hz	AC220V 50/60Hz
input power	240W	245W
Maximum load	Can be equipped with up to 6 sets of mini rotary evaporation units	Can be equipped with up to 6 sets of mini rotary evaporation units
Dimensions(mm)	deep 350×width 170×high 350

Vacuum controller

Technical parameter	eC35	eC35s
Vacuum degree control range	20-1050mbar	10-1050mbar
Vacuum setting accuracy	1mbar	1mbar
Vacuum degree control accuracy	5mbar	2mbar
Display screen	5 inch TFT touch screen	5 inch TFT touch screen
Vacuum control order	5	5
Material contact part material	316 stainless steel	PEEK,PTFE,Perfluoroether rubber,PFA
Vacuum pump power control	N/A	Can control the start/stop of the vacuum pump
Communication Interface	N/A	RS485
Pneumatic interface specifications	316 stainless steel φ10mm Pagoda connector	PEEK φ10mm Pagoda connector
voltage	AC100-230V,50/60Hz	AC100-230V,50/60Hz
input power	50W	50W
Dimensions(mm)	deep 240×width 160×high170

Solvent Recovery Unit

Specification	eSR220s	eSR320s
Condense stage	Three stages	Three stages
Lowest temperature	-20ºC	-20ºC
Collection bottles	One	Two
Collection bottle Volume	1000ml	3000ml
Condensing pipeline ring material	Special material (Resistance to chloride)	Special material (Resistance to chloride)
Inlet interface specification	PEEK φ10mm Pagoda-Shape Connector	PEEK φ13mm Pagoda-Shape Connector
Outlet interface specification	PEEK φ10mm Pagoda-Shape Connector	PEEK φ12mm Pagoda-Shape Connector
Power supply	AC220V 50Hz	AC220V 50Hz
Overall dimensions	L(510mm)W(240mm)H(682mm)	L(510mm)W(340mm)H(710mm)

Glass condenser

Technical parameter	GL1000
Material	Borosilicate glass
Suction port	φ10mm Pagoda connector
Waterway interface	φ10mm Pagoda connector
Collection bottle volume	1000ml
Condenser tube surface area	0.2 m2
a fixed way	V35,V35sVacuum pump and T series Cooling circulating water machines have GL1000 installation interface, Can be easily suspended and fixed

Chiller

Specification	T4	T4α	T4β
Temperature Range	5-35ºC	-10-35ºC	-20-35ºC
Temperature Stability	±0.1ºC	±0.1ºC	±0.1ºC
Cooling Capacity	1600W @20ºC	1500W @20ºC	1200W @20ºC
Reservoir Volume	8L	8L	8L
Overall dimensions	490×246×790	490×246×790	490×246×790
Specification	T3	T3α	T3β
Temperature Range	5-35ºC	-10-35ºC	-20-35ºC
Temperature Stability	±0.1ºC	±0.1ºC	±0.1ºC
Cooling Capacity	1200W @20ºC	1000W @20ºC	800W @20ºC
Reservoir Volume	7L	7L	7L
Overall dimensions	460×210×660	460×210×660	460×210×660
Specification	T2	T2α	T2β
Temperature Range	5-35ºC	-10-35ºC	-20-35ºC
Temperature Stability	±0.1ºC	±0.1ºC	±0.1ºC
Cooling Capacity	700W @20ºC	600W @20ºC	500W @20ºC
Reservoir Volume	5L	5L	5L
Overall dimensions	410×210×560	410×210×560	410×210×560
Specification	T1	T1α	-
Temperature Range	5-35ºC	-10-35ºC	-
Temperature Stability	±0.1ºC	±0.1ºC	-
Cooling Capacity	450W @20ºC	300W @20ºC	-
Reservoir Volume	3L	3L	-
Overall dimensions	350×176×550	350×176×550	-

---
