Sotech is a professional manufacturer. We provide customers with various professional specifications of AR&VR equipment to meet the needs of various entertainment, commercial and industrial scenarios. At the same time, we can also provide customers with various professional displays such as transparent advertising screens and touch displays. screen equipment, please feel free to contact me for more information.
| OPTICAL |
| Model Type | Birdbath |
| Diopter | The diopter can be adjusted to 0 ~ -500 degrees |
| Ppupillary distance is optional |
| According to 63.5/58.5/67 |
| DISPLAY |
| Device Type | Si-OLED * 2 |
| Contrast | 100000:1 |
| Brightness | 2000nits |
| Resolution | 1920x1080xRGB @0.49 inch |
| Refresh rate | 75 hz |
| FOV | 41 ° |
| Virtual Screen | 63-320 inches (2m~10m) |
| Color | 24 |
| AUDIO |
| Speaker | Stereo speakers * 2 |
| INTERFACE |
| USB Type-C | Wired |
| Video I/F | DisplayPort Alternate Mode (DP Alt Mode) |
| DisplayPort | Version 1.4 |
| Audio codec | LPCM (32kHz to 192kHz) |
| EDID | Supported |
| Power | 5.0 V 0.5 A |
| USB protocol | USB2.0 |
| Data Type | Sensor data, firmware update |
| SENSOR |
| A compass | Yes |
| Gyroscope | Yes |
| Accelerator | Yes |
| KEYS |
| Short press width Key (+ / -) |
| 2D/3D Switch to Long Press Brightness Key (-) |
| Short press Volume Key (+ / -) |
| GENERAL |
| Operating temperature and Humidity 5°C~35°C, 20% to 80% Humidity |
| Store temperature and Humidity -10°C~60°C, 10% to 90% Humidity |
| W177 mm x D159mm x H48 mm x T12 mm (top) |
| Weight: about 68g (not including light shield, cable) |
| Accessories: nose rest (optional), sunglasses piece, adjusting screwdriver, erasing cloth |
