Product Description
Product Description
Product Description
AT388 Series Banbury Mixer (original HY3880) is used for plasticizing, scattering and mixing of rubber products, industrial chemicals and plastic products, such as rubber ring, rubber belt, PVC, color masterbatch, cable materials, etc.
Details & Features
Model
| AT388A
| AT388B
|
Volume
| 3L
|
|
Display
| LED
| Color touch screen
|
Main motor
| 5.5kw
|
|
Heating method
| Electric
|
|
Heating power
| 2.5kw
|
|
Temperature range
| RT~260℃
|
|
Dumping angle
| 135°
|
|
Dumping motor
| 0.75kw
|
|
Compressor motor
| 2.2kw
|
|
Speed ratio of front and
back rotors
| 1:1.27 or customized
|
|
Rotor speed
| 0 ~ 50RPM adjustable
|
|
Rotor hardness
| HRC 60 crmoly
|
|
Mixing room
| SKD crmoly with HRC60 hard chrome
|
|
Air pressure
| 0.5 ~ 0.8Mpa
|
|
Power supply
| 3phase, AC220/380V, 60/50Hz
|
|
Dimensions
| 1450×700×2200mm
|
|
Weight
| 980kg
|
|
Specification
★ PLC control, self-examination, alarm and interlock function★ Large color touch screen control, programmable, real time display time, temperature, torque (HY3880B).
★ It has real time discharge function during working to avoid motor stop and start frequently, it can protect the motor and make it work for long time
★ Adopt hard surface planetary reducer, excellent quality
★ Electric heating or/and water cooling optional for one machine
★ Different mixing capacity selectable
★ Excellent mixing effect, high efficiency
★ Easy to operate and maintain, lower power consumption, stable and safe
Our Company
History
Since 1982 with more than 20 years’ experience
Warranty
Two Year Warranty for whole product
Training
Video and user manual for training
Onsite service
Installation and training service is available
Testing service
Free sample testing before order is available
Lead time
15 working days lead time for most product
Packing & Delivery
Packaging
|
|
Dimensions
| 1450×700×2200mm
|
Weight
| 980kg
|
Packaging Details
| 1. The equipment is covered with film is protect it from water vapour during the trip.
2. The box is filled with foam to protect the equipment from impact.
3. Exported wooden box made from plywood, don't need fumigated.
|
Payment
Payment Term
|
T/T
| EXW
|
30% T/T in advance, paid the balance before shipment
|
|
| FOB
|
|
|
| CFR(C&F)
|
30% T/T in advance, paid the balance against copy of B/L
|
|
| CIF
|
|
| L/C
| L/C amount above 50,000 usd, we can accept L/C at sight
|
|
| West Union
|
Amount lower than 5000usd
|
|
| West Union
|
|
|
Delivery Time
| 7~10days after receiving payment for one container
|
|
|
