Improved Paper Bowl Machine (WJ-80)

Product Description

MACHINE INTRODUCTION
WJ-80 Middle-speed paper bowl forming machine is a machine that developed on the technique of Korea machine. It has the function of automatic paper feeding, preheating, sealing, oil injection, bottom cutting, heating, knurling, curling, and so on. It can alarm via sensor checking, counting and collecting itself. WJ-80 paper bowl machine is an equipment both for single and double PE coated paper bowl, making soup bowls and noodles bowl etc.
MAIN TECHNICAL PARAMETER

Name	Middle Speed Paper Bowl Machine
HS Code	8441309000
Model	WJ-80
The machine includes: Finished Bowl Collect System
Paper bowl Size	TOP DIAMETER=90mm-140mm	BOTTOM DIAMETER=70mm-110mm
	BOWL HEIGHT=50mm-110mm	DOTTOM DEPTH=5mm-11mm
Raw Material	One-side or two-side PE coated paper(Singe PE or Double PE coated paper)
Speed	80-100pcs/min
	Speed of 20 hours stable running per day
Suitable paper weight	170-350gsm
Voltage supply	380v50hz 3-phase *If user's voltage supply is different, please inform us in advance.
Working Air Source	Air pressure 0.6-0.8Mpa, 0.4m3/min User should buy Air Compressor
General power	10kw
Net weight	2500kgs
Measurement (mm)	2200*1200*1800
We can customize machine and mold according to customer's requirement.

AFTER SERVICE
1. Paper Bowl Machine warranty: 1 year
2. the guide booklet will be sent with machine to guide the installation process works, adjust the whole machine, production,
3. we will adjust the machine well for one week before the delivery,
4. we can dispatch technologists to buyer's factory, guiding installation, adjustment for a period,
5. we supply the free training of buyer, the training won't stop until the buyer control the whole lesson!
6. we supply the consumable spare parts for free for one year use.
FACTORY VIEWE
Ruian Lifeng Machinery Co., Ltd (old name: Ruian Sincere Machinery Co., Ltd. ) is a manufactory specialize in producing series of automatic machinery for paper containers like paper cup making machine, paper bowl forming machine, ice cream cone sleeve machine, die punching machine etc. Especially the water cone cup machine, we get the patent in China. And all of our products have past CE, SGS. In last 10years, we exported to all of the world and get good feedback from our customers.
We pursue "quality first, service paramount". Welcome the clients at home and abroad to negotiate and cooperate.

---
