| E30 | E50 |
Print head
| 32mm 300dpi
| 53mm 300dpi
|
Print head without aire
| One botton to make the print head automatically aligns and start to print without shims or tools
|
Print area
| Intermittent: 32mm x 75mm
| Intermittent: 53mm x75mm
|
Continuous: 32mm x 200mm
| Continuous: 53mm x 200mm
|
Max. print speed
| Intermittent: 2-30 m/min
|
Continuous: 0.5 - 36 m/min
|
Max. print frequency
| Intermittent: 350 times/min
|
Continuous: 450 times/min
|
Language
| Your mother language software system
| Your mother language software system
|
keyboard
| Your mother language keyboard
| Your mother language keyboard
|
Ribbon length
| 800m(out)
| 800m(out)
|
Ribbon width
| 22-33mm
| 33-55mm
|
Capable content
| Dat&Time, Variable Info, Image, Table Info, Barcode, QR Code, Serial Info, etc.
|
Barcode, QR Code
| Codel 28(GS1), EANX, Codel 1, QRcode(GSI), C25matrix, C25inter, C25iata, Upca,UDI,
|
Upce, EAN 128, PDF417, DataMatrix(GSI), and other variable code types.
|
Touch screen controller
| Hot plugging supported，computer screen (wifi, blueteeth) write directly on screen(by hands or by mouse)
|
Text font
| Supports true type fonts, including non-Roman characters and symbols
|
Storage
| Print Unit （512MB)，Screen controller (16GB)
|
Capable function
| Controller, Code sending print, Multiple controlling programs with data exchange protocol
|
Communication
| RS232, Ethernet, Window supported data exchange protocol.Blue teeth
|
Interface language
| English, Spanish, Portuguese, French, Arabic, German, Russian, Simplified/Traditional Chinese, etc.
|
Calender type
| Gregorian calendar, Persia calendar, Islam calendar
|
Saving/Assisting mode
| Ribbon Saving Mode, Radial Print Mode, Equal Spaced Mode, etc. (Multi-appliaction available)
|
Dimension (Print Unit)
| 210mm x 170mm x 180mm
| 210mm x 190mm x 180mm
|
Weight (Print Unit)
| 7.8KG
| 8.0KG
|
Dimension (Controller)
| 240mm*15mm*120mm (7inch)
| 260mm*30mm*180mm(10inch)
|
Weight (Controller)
| 0.75 kg
|
Power supply
| AC100-240V,50/60Hz
|
Power
| 200W
|
Operation Env.
| Temperature: 0-40°C Humidity: 10-90% (Non-condensing)
|
Operation Air Pressure
| No need (we are aireless tto )
|
