Volumetric Mixer Automatic Proportional Mixing of New Materials Color Masterbatches

Product Description

Product Description

Controlled by microcontroller, and consists of LCD screen and keyboard.e Simple operating sstem interface with troubleshooting tunction.
Equipped with imported brushless gear motor that is free from maintenance.Conveying accuracy is between 1% and 5%.
Store up to 50 program recipes.
Automatically stops and alarms for material shortage(optional).jammed conveyor, and overloaded motor.
Modularized stuture for easy inltlalo maintenance and replacement.Chrome plated screw is reliable.
2 ports for exenal inputs (ie. ijectiono molding machine and extrudermachine).
There re2 szes of screw avalble for dfent output requretCleaning function can discharge residual materials.
Alserte can be opon equiped with bender for beter ming terils
Taizhou Taima Automation Technology co,LTD, founded in 2009, has beencommitted to the plastic molding automation equipment research anddevelopment work in innovation, based on one-stop service turn-keyproject, continuously development introduced international advancedhigh-tech environmental protection products.
Units of unremitting efforts to participate in the scheme the trial productionof new products, assist you more quickly and more economic highvalue-addeproducts, for customers to create the first-class factoryautomation, realize the goal of win-win, create greater wealth for clients.
The company is located in China mold town-taizhou huangyan, is a collectionresearch and development, manufacturing, quality assurance. sales throughtrain enterprises. Product Parameters

sechnicalparameter
Model	TMV-40	TMV-60
Power	220V 50/60Hz 1P	220V 50/60Hz 1P
Single screw handling capacity	0~150kg/h	0~1400kg/h
Power of screw motor	60Wx3	90Wx3
Stiring motor power	120W	120W
Bucket capacity	18L	18L
The screw diameter	40mm	60mm
Dimensions	950x850x950mm	950x850x950mm
Product weight	90kg	95kg

Detailed Photos

---
