US$8,500.00-10,850.00
|
1 Piece
(MOQ)
|
Basic Info.
Carrying Capacity
Light Level
Feature
Aerial Work Platform
Size of Platform
2.27×1.12 M
Platform Extension Size
0.90×1.12 M
Production Capacity
500PCS/Month
Product Description
CONFIGURATION:
1, Battery :Trojan from USA
2, Drive motor: Changba or Changqian from China
3, Charger : Keneng from China
4, Control system: DTC from USA
5, Group valve: Hydraforce from USA
6, Motor & braking : White from USA
7, Oil Pump: Bravini from ITALY
8, Tyre :Exmiletyre from China
9, Filter: Donaldson from USA
| Model | S10 |
| Max.working height | 12m |
| Max.platform height | 10m |
| Loading Capacity | 320KG |
| Size of platform | 2.27×1.12 M |
| Platform extension size | 0.90×1.12 M |
| Overall stowed height(lift) | 2.44M |
| Overall stowed height(lower) | 1.92M |
| Overall stowed length | 2.435M |
| Overall stowed width | 1.15M |
| Power | 24V/3.3KW |
| Driving speed-Eleveted | 3.5KM/H |
| Driving speed -Lowered | 0.8KM/H |
| Lift/Lower time | 45/36sec |
| Battery | 4×6V/225AH |
| Max climbing ability | 25% |
| Maxmum slope | 3° |
| Wheel size | φ381mm×127mm |
Extend platform
safe working load | 113KG |
| Total weight | 2620KG |
>>
