Polished Thick Steel Plate for Ink Try Pad Printing Printer
video:/v_show/id_XNjM0NzQ1MDk2.html
| Thick Steel clichés size | Thickness 10mm |
| (3"X3") 75X75 mm | Thickness 10mm |
| (3"X4") 75X100 mm | Thickness 10mm |
| (3"X5") 75X125 mm | Thickness 10mm |
| (3"X6") 75X150 mm | Thickness 10mm |
| (3"X7") 75X175 mm | Thickness 10mm |
| (3"X5") 75X200 mm | Thickness 10mm |
| (3"X24") 75X600 mm | Thickness 10mm |
| (4"X4") 100X100 mm | Thickness 10mm |
| (4"X5") 100X125 mm | Thickness 10mm |
| (4"X6") 100X150 mm | Thickness 10mm |
| (4"X7") 100X175 mm | Thickness 10mm |
| (4"X8") 100X200 mm | Thickness 10mm |
| (4"X10") 100X250 mm | Thickness 10mm |
| (4"X12") 100X300 mm | Thickness 10mm |
| (4"X14") 100X350 mm | Thickness 10mm |
| (4"X16") 100X400 mm | Thickness 10mm |
| (4"X18") 100X450 mm | Thickness 10mm |
| (6"X6") 150X150 mm | Thickness 10mm |
| (6"X8") 150X200 mm | Thickness 10mm |
| (6"X10") 150X250 mm | Thickness 10mm |
| (6"X12") 150X300 mm | Thickness 10mm |
| (6"X14") 150X350 mm | Thickness 10mm |
| (6"X16") 150X400 mm | Thickness 10mm |
| (8"X8") 200X200 mm | Thickness 10mm |
| Available Sizes: | Virtually any size cliché is available. We stock most of the industries popular sizes for a variety of machine brands and models. |
| Cliché Thickness: | 10mm (0.39") |
| Etch Depth: | May be varied depending on the percent of the screen tint film and exposure time. |
| Attributes: | Thick Steel cliché material, highly polished finish with photo sensitive emulsion. Finest print quality. Rockwell Hardness: ~63. |
Technical parameters:
| Style | hight Quality oil steel | Imported oil steel | Chromium steel |
| Material Composition | GCr15 | 9CrWMn | 9Cr12MoV |
| Surface heat treatment hardness | HRC63±1 | HRC63±1 | HRC62±1 |
| Board flatness | Ink cup:500:0.05mm
Ink tray:500:0.005mm | Ink cup:500:0.05mm
Ink tray:500:0.005mm | Ink tray:500:0.05mm
Ink tray:500:0.005mm |
| Board surface finish | matt:Ra0.1μm
glossy:Ra0.01μm
mirror: Ra0.005μm | matt:Ra0.1μm
glossy:Ra0.01μm
mirror:Ra0.005μm | matt:Ra0.1μm
glossy:Ra0.01μm
mirror: Ra0.005μm |
| Rust force | First class | Second class | Fifth class |
| Scratch Views | 150,000 impressions | 300,000 impressions | 1000,000 impressions |
| Plate thickness range of processing | 10.2-10.5mm |
10-15mm | 10mm |
| Applications | Abs pet pvc pe,etc ink | Abs pet pvc pe,etc ink |
Pp Highly corrosive ink
|
