| Material | |
| Contacts | Copper alloy |
| Insulator | High temperature thermoplastic |
| Plating | |
| Contact area | 0.8um Au |
| Solder area | 4um Sn |
| Underlayer | 2um Ni |
| Electrical Specifications | |
| Contact Resistance | Max. 100m ohm |
| Voltage Rating | Max. 15 Vdc SLEV |
| Current Rating | 1A |
| Dielectric Strength | Min. 500Vrms |
| Insulation Resistance | ≥10E9ohm |
| Climatic Characteristics | |
| Operation Temp | -40°C~ +85°C |
| Mechanical Specifications | |
| Contact Force, nominal | 30-70 cN |
| Mechanical Lifetime | Min. 1500 mating cycles |
