| US$2.50-10.00 | 50 Pieces (MOQ) |
| Model | 2W160-10 | 2W160-15 | 2W200-20 | 2W250-25 | 2W350-35 | 2W400-40 | 2W500-50 |
| Working Medium | Air,Water,Oil,Gas | ||||||
| Motion Pattern | Direct Drive Type | ||||||
| Type | Normal Close Type | ||||||
| Aperture of Flow Rate(mm) | 16 | 20 | 25 | 35 | 40 | 50 | |
| CV Value | 4.8 | 7.6 | 12 | 24 | 29 | 48 | |
| Joint Pipe Bore | 3/8″ | 1/2″ | 3/4″ | 1″ | 1 1/4″ | 1 1/2″ | 2″ |
| Operation Fluid Viscosity | 20 CST(Below) | ||||||
| Working-pressure MPa | Air:0~0.7MPa; Water:0~0.5MPa; Oil:0~0.5MPa | ||||||
| Max. Pressure Resistance MPa | 1 | ||||||
| Operating Temperature ºC | -5 ~ 80ºC | ||||||
| Voltage Range | ±10% | ||||||
| Material of Body | Brass (Material of stainless steel need special explain) | ||||||
| Symbol/Model | A | B | C | D | E | F | K |
| 2W160-10 | 101.5 | 57 | 117 | 67 | 50 | 36 | G3/8″ |
| 2W160-15 | 101.5 | 57 | 117 | 67 | 50 | 36 | G1/2″ |
| 2W200-20 | 107 | 57 | 123.5 | 72 | 50 | 36 | G3/4″ |
| 2W250-25 | 111.5 | 73.5 | 134.5 | 92 | 50 | 36 | G1″ |
| 2W350-35 | 142 | 95 | 172 | 125 | 70.5 | 56 | G1 1/4″ |
| 2W400-40 | 142 | 95 | 172 | 125 | 70.5 | 56 | G1 1/2″ |
| 2W500-50 | 172 | 123 | 209 | 168 | 70.5 | 56 | G2" |
| NO | Name |
| 1 | Body Of Valve |
| 2 | Assembly Of Diaphragm |
| 3 | Valve Cover |
| 4 | Pull Spring |
| 5 | Gasket |
| 6 | Socket Hexagon Screws |
| 7 | Assembly Of Iron Core |
| 8 | Seal Gasket |
| 9 | Assembly Of Iron Core |
| NO | Name |
| 10 | Magentic Plate |
| 11 | Spring |
| 12 | Assembly Of Iron Core |
| 13 | Iron Cover |
| 14 | Cord-Locks |
| 15 | Name Plate |
| 16 | Gasket |
| 17 | Head Cover Nut |
