High Performance Plastic Pai Rod

Product Description

High performance plastic PAI rod
The TORLON®PAI grades, is one kind of new acyl engineering plastic. Guangzhou Engineering Plastics Industries (Group) Company, has studied and applied this material in many industries for many years. As the molecules of TORLON®PAI, has a rather steady heterocyclic structure inside, which has the excellent performances of intrinsic high and low temperature resistance that other macromolecule materials can't compare with, and has excellent mechanical strength and dimensional stability resistance. Especially: high temperature resistance,high strength,high insulation,anti-radiation,chemical corrosion-resistance,self-lubrication and extremely low thermal expansion.

Main characterastics very high max. allowable working temperature in air (250°C continuously) extremely low coefficient of linear thermal expansion up to 250°C excellent retention of mechanical strength, stiffness and creepage resistance over a wide range of temperatures. excellent wear and frictional behavior (particularly TORLON®4301PAI) exceptional resistance against high energy radiation(γradial and Χradial). inherent low flammability
PAI rod
Propertites for your reference:

Property		Item No.	Unit	PEEK-1000	PEEK-CA30	PEEK-GF30
Mechanical Properties	1	Density	g/cm3	1.31	1.41	1.51
	2	Water absorption(23ºC in air)	%	0.20	0.14	0.14
	3	Tensile strength	MPa	110	130	90
	4	Tensile strain at break	%	20	5	5
	5	Compressive stress(at 2%nominal strain)	MPa	57	97	81
	6	Charpy impact strength (unnotched)	KJ/m2	No break	35	35
	7	Charpy impact strength (notched)	KJ/m2	3.5	4	4
	8	Tensile modulus of elasticity	MPa	4400	7700	6300
	9	Ball indentation hardness	N/mm2	230	325	270
	10	Rockwell hardness	-	M105	M102	M99

FAQ:
1.A: What's the size of plastics sheet?
B:Nylon sheet:Thickness*Width*Length:20-100*1000*2000mm
UHMW-PE sheet:Thickness*Width*Length:20-100*1000*2000mm; 20-100*1250*3130mm; 20-100*1250*4250mm
POM sheet:Width*Length:1000*2000mm

2. A:Can we purchase a small part of plastics sheet?
B: Yes,you can, if we have the size you require in stock.

3. A:What color of plastics sheet?
B: Nylon sheet: Natural,black,blue,or according to client's requiremnet.
UHMW-PE sheet: White,black,green ,bule,yellow,or according to client's requirement.
White,black
4. A:Can you manufacture the plastics products as per drawing?
B: Yes,we can.

5.A: What the precision of plastic products according to drawing?
B: Different machine with different precision,it usually around 0.05-0.1mm

6.A: What the technologies in producing plastics parts?
B: Different products with different technologies,such as CNC machine,Extrusion,Injection

7: A:What kinds of processing machine do you have?
B: CNC machining center,CNC lathes,Milling,Injection Molding Machine,Extruder,Moulding press

---
