Counter-Drone Defense Solutions and Systems

Product Description

Product Description
Counter-Drone Defense Solutions and Systems
The TXPD3000 drone detection radar is a 3D radar that is costeffective with great performance, supporting 360° continuous detection of mini-UAVs up to 3 km. It has the capability to identify up to 50 targets simultaneously with distance, azimuth, height, and speed data. It is perfect for anti-UAV application for correctional facilities, airports, critical infrastructures, oil refineries, and national events etc.
TXPD3000 Specification:

Radar Detection Range	3 km/5km
Azimuth Coverage	360°
Target Capacity	50 targets simultaneously
Scan Rate	60°/s
Communication Interface	RS485/10/100M Ethernet
Display Interface	10/100M Ethernet
Weight	25 kg
Dimension	740 X 600 X 600 mm
Operating Temperature	-20°C to + 60°C
Power Consumption	150 W
IP Level	IP65
MTBF	100000
Power Supply	AC:110 V (AC:220 V Optional)

Application Scenarios
ANTI-DRONE SYSTEM Anti-Drone System Features 1.Multi-sensor system for drone detecting, tracking, identifying and neutralization.
2.360° active detection & omni directional coverage.
3.Affordable hardware with smart software.
4.Windows-based OS with activated "point-and-click" zoom & deterrent activation.
5.Operates in all weather conditions.
6.Open architecture.
7.Easily integrated, compatible with other security and display systems. System Details 360° Radar Detection System
360° Radar Detection System is affordable, light weight and portable. It offers 360° continuous coverage of up to 3 km. It is smart, with the ability to identify the range, azimuth, elevation and velocity measurement of up to 50 targets while calculating their distance and time of arrival.
Features: 1.Detect all targets regardless of frequency bands 2.High resolution 3.High success rate of target detection 3km 5.Affordable Specifications: 360° RF Detection and Neutralization System This passive RF detection and neutralization system is highly compatible. It's able to detect, identify and neutralize targets up to 1.5 km.
Features 1.360° detecting and neut 2.Up to 3 km detection range 3.Up to 1.5 km neutralization range Specifications:

Frequency Ranges	430-440 MHz 10 W (Optional)
		900-930 MHz 20 W (Optional)
		5710-5900 MHz 20 W
		2400-2505 MHz 20 W
		1550-1620 MHz(GPS) 10 W
Neutralization Range	1.5 km
Max Power Consumption	330 W
Operating Temperature	-25°C to +55°C
Weight	≤14 kg
Dimension	401 X 404 X 571 mm

Software Platform
We tailored our smart software so that our customer can enjoy unlimited coverage by combining multiple devices into an integrated sensor network.
Features:
1.Easy to use Windows-based OS to integrate multiple sensors onto one display 2."Point-and-roll" or "double-click" zoom in/out 3.One-click deployment and deterrent activation 4.Customizable alarm zones 360° or sectional scan 5.Reports with detailed information and statistics.

---
