High Precision and Efficiency Ck6132 Instrument CNC Lathe

Product Description

The CK6132 digital control lathe has several significant advantages compared to traditional CNC lathes:
High Precision: The CK6132 digital control lathe employs more precise measurement and control technologies, enabling higher machining accuracy and stability. Real-time measurement of the workpiece and tool positions allows for timely compensation, reducing machining errors and enhancing precision.
High Efficiency: During machining, the CK6132 lathe can monitor the status of workpieces and tools in real-time, adjusting machining parameters accordingly to effectively improve machining efficiency. Precise control of the machining process also reduces debugging and scrap rates, thereby increasing overall production efficiency.
High Automation Level: Integrated with advanced sensors and automatic control systems, the CK6132 lathe achieves a higher degree of automated machining. Operators typically only need to set machining programs and monitor the process, significantly lowering skill requirements and reducing errors caused by human factors.
Strong Adaptability: The CK6132 lathe can accommodate complex machining requirements and diverse types of workpieces. Flexible programming and adjustments enable quick adaptation to different machining tasks, reducing setup and changeover times and improving equipment utilization.
Data-driven Management: The CK6132 lathe allows for recording and analysis of machining data, facilitating optimization and management of the production process. Through data analysis, potential issues can be identified and addressed, further enhancing production efficiency and quality.
Overall, the CK6132 digital control lathe offers clear advantages over traditional CNC lathes in terms of precision, efficiency, automation, adaptability, and data-driven management. It is a key equipment widely applied in modern manufacturing industries.
Product Parameters

ITEM	PARAMETERS
CNC system	GSK
Swing over bed	300mm
Max. rotation diameter of the support plate	180mm
X-axis Max. strok	600mm
Z-axis Max. strok	550mm
X-axis rapid traverse speed	8000mm/min
Z-axis rapid traverse speed	8000mm/min
Spindle through-hole	48mm
Spindle head specifications/taper	A2-5/21°
Main motor power	4/5.5kw
Spindle speed	3000rpm
Tool holder form	Four-position tool turret
Tool handle specification	20*20mm
Quasi compact mode	Pneumatic clamping/Three-claw chuck
X-directiong motor torque	4 Nm
Z-directiong motor torque	4 Nm
X/Z motor connection method	Direct connection
X-axis lead screw specification	2506
Z-axis lead screw specification	4006
Tailstock center cone hole	MT-4
Repetitive positioning accuracy	0.01mm
Positioning accuracy	0.02mm
Cooling water pump power	120w
External dimensions of machine tools	1900*1300*1600mm
Net weight of machine tool	1200kg

---
