Wood Corner Jointing Machine with High Frequency Heating

Product Description

Introduction:
Wood corner joining machine is also named HF corner jointer, high frequency corning jointing machine. It is applied high frequency dielectric heating technology, which only heats the glue line, safely and efficiently. Different angle of wooden frame/MDF frame, PVC wrapped, paper wrapped frame and painted frame can be assembled 5-10 seconds, which can help customer improve the efficiency and save labor costs. It does not need nail. Can make sure the good looking of frame. Widely used for photo frame, mirror frame, cabinet door, and closet door assembly.
Features:
Free adjustment working table can meet different angle frame corner joining PLC control the whole process automatically. Convenient and easy to operate International electric components, stable and durable Humanization design on foot pad control: One more choice besides PLC auto control. When join long and big frame, can set hands free to hold the frame.

Model	HFCJ-13-CH	HFCJ-13-S-CH
Voltage	Single phase AC 220V 50Hz	Single phase AC 220V 50Hz
Power	3-5KW	3-5KW
Heating time	5-10 seconds	5-10 seconds
Frequency	13.56MHz	13.56MHz
Stapler function	Not including	Including
Overall size	800x1200x1250mm	1150x1200x1250mm
Total weight	200kg	250kg

This type can do both types of jobs: Stapler on the left side. Or apply high frequency heating on the right side.Customer can select the machine working type according to production technology.

---
