| 320 mm | Bore diameter |
| 480 mm | Outside diameter |
| 121 mm | Width |
| ≈375 mm | Shoulder diameter of inner ring |
| ≈441 mm | Shoulder or recess diameter of outer ring |
| max.23.3 mm | Permissible axial displacement |
| min.4 mm | Chamfer dimension |
| Basic dynamic load rating | 2 280 kN |
| Basic static load rating | 4 000 kN |
| Reference speed | 1 000 r/min |
| Limiting speed | 1 400 r/min |
| Product net weight | 75.7 kg |
| Number of rows | 1 |
| Locating feature, bearing outer ring | Without |
| Bore type | Tapered 1:12 |
| Cage | Machined metal |
| Radial internal clearance | CN |
| Tolerance class | Normal |
| Sealing | Without |
| Lubricant | None |
| Relubrication feature | Without |
