Product Details
Product Description
Product Description
Focus on DCS, PLC, robot control system and large servo system.
Main products: various modules / cards, controllers, touch screens, servo drivers.
Advantages: supply of imported original products, professional production parts,
Fast delivery, accurate delivery time,
The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands
The adapter replaces the optional ACS100-PAN control panel. To eliminate the stress caused by the cables, use a strain relief. Selecting the Communication Speed Communication speed is selected by DIP switch S1 and by parameter 5201 COMM SPEED. The factory setting for the communication speed is 9600 bps (bits per second). Communication speed setting using DIP switch S1 is needed only when the adapter operates in RS485 mode. Figure 2 Selecting the communication speed for the adapter. DIP switch S1 Communication speed 300 bps 600 bps 1200 bps 2400 bps 4800 bps 9600 bps 19200 bps ON ON ON ON ON ON ON 5 INSTALLATION Selecting RS485 or RS232 Mode The adapter operates either in RS232 mode or in RS485 mode, selectable by a jumper. As a factory setting, the adapter operates in RS485 mode. Figure 3 Selecting the operating mode. RS485 Bus Termination The RS485 bus must be terminated using 120 Ω resistors at both ends of the network. The adapter has built-in termination resistors that can be enabled by jumpers S2 and S3. Refer to “Earthing and Termination” on page 10. By default, bus termination is enabled. Figure 4 Selecting RS485 termination impedance. Jumper S5 Mode RS485 RS232 1 2 S5 S2 S3 Jumper S2 Jumper S3 Both jumpers S2 and S3 must be connected in order to obtain 120 Ω. If no termination is needed, both jumpers S2 and S3 must be opened. 6 Installation to RS485 Bus 1 Make sure power is not connected to the ACS140. 2 Connect the ACS100-PAN control panel to the drive. 3 Connect power to ACS140. 4 Set up communication: station number, communication speed of the ACS 140 and parity. Refer to Chapter 3 – Programming. 5 Set up other drive parameters as needed. Refer to ACS140 Programming Guide and chapter 3 of this manual. 6 Disconnect power from the ACS140. 7 Set communication speed of the adapter with DIP switch S1. 8 Confirm that the operation mode is RS485 (jumper S5). 9 If the termination is not needed, remove jumpers S2 and S3 to disable it. 10 Connect the adapter to the ACS 140 and wire it to the RS485 network. Skip steps 2-6 if the default parameter settings of the ACS 140 can be
>>
