| US$30,000.00-31,000.00 | 1 Piece (MOQ) |
| Machine Model | SKC-300 | |
| Type | CNC milling machine (cast steel) | |
| Structural style | three-sided | |
| Total machine power (Kw) | 37 | |
| Spindle speed(r/min) | Manual variable frequency stepless speed regulation | |
| Height between spindle center and work surface(mm) | 400 | |
| Maximum machining diameter(mm) | Φ550 | |
| Diameter of chuck(mm) | Φ400 | |
| Maximum distance between two cutters(mm) | 1100(without tool) (customizable) | |
| Z axis unilateral stroke(mm) | 350 | |
| Standard tool length (unilateral)(mm) | 200(Can be customized lengthening or shortening according to customer requirements) | |
| Theoretical minimum machining length(mm) | < 50 | |
| Fast feed speed(mm/min) | 1000 | |
| Main motor power(KW) | 7.5 KW | |
| Machine tool bearing | Harbin bearing | |
| X-axis feed motor | servo 10 N.M (System manufacturer matching) | |
| Z-axis feed motor | servo 15 N.M (System manufacturer matching) | |
| Machine tool guide form | Hard rail (single side V rail) (high frequency hardening) | |
| Machine bed | Three-sided bed (solid casting)HT250 | |
| Feed transmission mechanism | X-axis | ball screw |
| Z-axis | ball screw | |
| lubricating system | Electronic lubrication pump | |
| Chuck style | Double dovetail | |
| Compaction mode | Hydraulic compression, frame type compression bracket mobile beam | |
| Operating system | Xinkerui 980TDca or customer specified | |
| Machine tool electric appliance | Delixi | |
| Form of protection | Machine tool protection is an integral sheet metal protection type, including spiral chip removal and chain plate chip removal, including cooling system, including cart | |
| Type of cooling | customers requirement | |
| Machine color | White on top and gray on bottom (or customer specified color) | |
| Attachment | Machine tool cushion iron, anchor bolt, cutting tool, tool bar | |
