Leyo Hmc-100 Xyz Trave 1600/1000/1000 mm Horizontal Machining Center

Product Description

Leyo HMC-100 Horizontal Machining Center

LEYO HMC-100 Horizontal Machining Center Technical Parameters
Item	Unit	HMC-100
Size	mm	1000x1000
Number		1
size		1°X360
Exchange time	S	-
Max load	kg	1600
T-groove(numberofslots×Groovewidth×Spacing))	mm	7x22x125
Max workpiece rotation diameter	mm	1800
Max speed	r/min	10
X(table moves left and right)	mm	1600
Y(spindle moves up and down)	mm	1000
Z(Table/column moves forward and backward)	mm	1000
X/Y/Zfast moving speed	m/min	24
Distance from spindle center to workbench	mm	0-1000
Distance from spindle endface to workbench Center	mm	250-1250
Spindle taper hol edegree No		ISO7:24No.50
Max spindle speed	rpm	4500
Spindle motor power	kw	22/26
Spindle motor Maxtorque	Nm	770
Capacity	T	40
Max tool diameter*length	mm	125x400
Max too ldiameter(adjacentnotool)	mm	250
Max tool weight	kg	25
Tool change time(tooltotool)	s	4.75
Positioning accuracy(XYZ)	mm	0.01
Positioning accuracy(axisB)	"	10
Repeatpositioning accuracy(XYZ)	mm	0.006
Repeatpositioning accuracy(axisB)	"	2
Appearance dimension of sheet metal	mm	6500x4700x3700
Netweight of optical machine	kg	10500
Controller	GSK/LNC/Syntec/Mitsubishi/Siemens/Fanuc

FAQ
1.What are the two types of horizontal milling machine?
There are two types of horizontal milling machines: plain horizontal milling machines and universal horizontal milling machines.
Plain horizontal milling machines have a fixed spindle and an adjustable table that can move in a horizontal plane. The cutting tool is mounted on a horizontal arbor and rotates in the opposite direction of the workpiece. This type of machine is used for simple milling operations and is ideal for producing flat surfaces, slots, and keyways.
Universal horizontal milling machines have a swivel table that can be adjusted to any angle, allowing for more complex milling operations. In addition to the horizontal spindle, these machines also have a vertical spindle that can be adjusted to different heights. This allows for the production of angled surfaces, grooves, and other complex shapes. Universal horizontal milling machines are more versatile than plain horizontal milling machines and are commonly used in the manufacturing industry.
Dongguan Liyang Intelligent Technology Co., Ltd., located in Houjie Town, Dongguan City, Guangdong Province, China, is a manufacturer of CNC machine integrating industry and trade. Its main products are high-end 3-5 axis CNC milling machines like high-speed cnc milling machines, gantry milling machines, etc; cnc machining center like vertical machining center, horizontal machining center, vertical horizontal dual-use machining center, compact machining center, etc; and cnc lathe, etc. These machines are mainly used in the producing and machining of parts and molds in 3c electronics, automobiles, instruments and meters, electronic appliances, medical devices, aerospace, machinery manufacturing, new energy vehicles, 5G communication industries and other industries. Our company has obtained several utility model patents and invention patents, CE certificates, ISO9001 quality management system certificates, and factory strength certification from SGS, TUV and other international testing and certification institutions. Our machinery and equipment are sold to the domestic and foreign markets. The main domestic markets are Guangdong, Zhejiang, Fujian, Sichuan and many other provinces. The international market is mainly exported to Europe, Central Asia, Southeast Asia and other countries. Our goal is to provide the world with high-quality CNC machine.
About LEYO service
1. Customized service
1. Design logo for free or remove logo services.
2. Free design of sheet metal. If you want the color of the machine appearance to be consistent with the color of your company's brand or factory decoration, we also provide free custom sheet metal design services.
3. Customized machine configuration for free. Customized according to customer configuration requirements, such as the brand and model of screw rod and linear guide rail, the brand power and speed of spindle, the brand and model of controller, and the type of tool magazine.
4. Customized special machines for free. If you have special requirements on the material, process, precision and efficiency of the products you are processing, we can customize the models based on the products you are processing.
5. Free design of automatic production line.
The customization quantity and price will vary according to the complexity of customization.
2. One stop procurement service
Provide accessories, four five axis turntable, tailstock, tool setting instrument, measuring head, chain chip conveyor, etc. Consumables like tools, tool handles, tool carts, tool boxes, etc.
3. Free online and offline after-sales service
The warranty period of all models is one year, and spare parts and online and offline after-sales services are provided free of charge within one year. However, the travel expenses of after-sales personnel need to be paid by the customer, such as transportation, board and lodging.Lifetime free online after-sales technical guidance service.
4. Fast delivery service
If you need it urgently, please tell me the expected delivery date, and we can arrange it according to customer needs. The fastest production time is 7 working days.

---
