Slow speed mining electric winch for raking ore

Product Details

Product Description

Product Description
Slow speed mining electric winch for raking ore
2JP, 2JPB series rake winches (hereinafter referred to as winches) are mainly used for ore handling and filling in metal mines and other mine pits or open pits. They are used for raking on slopes with a horizontal or inclination angle of no more than 44°.
Mine harrow winches are strictly forbidden to be used to carry people. Non-flameproof harrow mine winches are strictly prohibited to be used in coal mines! After the motor is started, it is strictly forbidden to press the two joysticks at the same time!

Model		2JPB-7.5	2JPB-15	2JPB-22	2JPB-30
		2JP-7.5	2JP-15	2JP-22	2JP-30
Average pulling force of main wire rope Kn		8	14	20	27.5
Wire rope speed	Main wire rope m/s	1.0	1.10	1.20	1.20
	Sub wire rope m/s	1.0	1.50	1.60	1.60
	Average m/s	1.0	1.3	1.4	1.4
Motor	Model	YBK3-132M-4	YBK3-160L-4	YBK3-180L-4	YBK3-200L-4
		Y132M-4	Y160L-4	Y180L-4	Y200L-4
	kW	7.5	15	22	30
Main drum	Rope capacity m	45	80	80	70
	Drum dia mm	205	220	280	280
	Drum width mm	80	125	156	156
Main wire rope	Dia mm	10	12	14	16
	Structure	6×19
	Minimum breaking force kN	55.8	80.4	109	143

Detailed Photos
The Special voltage of 440V that we designed for our South America Clients.
