| US$72,500.00-82,500.00 | 1 Set (MOQ) |
| 1. The general machine parameter | |
| Suitable roll forming material | Color steel sheet or galvanized steel sheet |
| Thickness | 2.0-3.0mm |
| Frame design | Wall-plate-frame-design /Strong-stand-frame-design |
| Roll stages | 17stages |
| Material of forming roller | 1. 45# steel, CNC lathes, Hard Chrome Coated 2. 40Cr, heat treatment, nitrided treatment |
| Shafts Diameter | Φ75/95mm |
| Main motor power | 18.5KWwith reducer |
| Max. Line speed of roll former | 8-10m/min (Higher speed is available, depends on the specification required by the buyer) |
| Hydraulic group power | 22KW |
| Material of cutting blade | Cr12, hear treatment |
| Electric Standard | 380V /50Hz/3PH or as the customer's requirements |
| Machine Dimensions | 9840mm×2030mm×1130mm |
| Major Color of Machine Painted | RAL 5015 (Blue) or as per customer's requirements |
| 2. PLC Control system | |
| PLC | Siemens brand (ABB brand is available if required) |
| Touch Screen | Siemens brand (ABB brand is available if required) |
| Inverter | Schneider brand (ABB brand is available if required) |
| Encoder | Omron brand |
| 3.Product rack | |
| Description | un-powered, 4 meters length |
| Option: Pre-Level Device Hydraulic Punching & Cutting M/C CE certificate Pl refer to the attached pictures for details | |
