| Specifications | |
| TFT Panel | |
| Model No. | QH750T |
| Panel size | 75" TFT-LCD |
| Display area(mm)/mode | 1764(H) x 1042(W)mm |
| Maximum resolution | 3840*2160 |
| Display color | 16.7M |
| Brightness (nits) | 300nits or 500nits |
| Contrast | 4000:1 |
| Visual angle | 178°/178° |
| Response time | 5ms |
| Life(hrs) | >60,000(hrs) |
| Touch | 10 point touch screen available |
| System | |
| Operating system | Android with free content management system |
| RAM | 2GB |
| ROM | 16G |
| Interface | HDMI input, USB, LAN |
| Appearance | |
| Color/appearance | White, Black, customized |
| Case | Metal case SPCC |
| Dimension(H*W*D)mm | 1800*1140*500 |
| Net Weight | 50kg |
| Installation | wall-mounted or embedded or floor-standing |
| Electricity | |
| Power supply | AC100~240V 50 /60 HZ |
| Maximum power consumption | 200w |
| Standby power consumption | <5w |
| Speaker | Yes |
| Temperature | |
| Working temperature | 0ºC~40ºC |
| Storage temperature | 0ºC~60ºC |
| Working humidity | 20%~80% |
| Storage humidity | 5%~95% |
| Detailed functions | |
| Video Format | MPEG1/MPEG2/MPEG4/DIVX/ASP/WMV/AVI |
| Audio Format | WAVE/MP3/WMA/AAC |
| Image Format | JPEG/BMP/TIFF/PNG/GIF |
| Image Resolution | 480P/720P/1080P |
| USB | Android/Wifi | Windows | |
| Content update method | Insert U-Disk | CMS or U Disk | CMS or U Disk |
| Operating system | Stand-alone | Android 4.4/5.1/6.0/7.1 | Windows 7/8/10/Linux |
| HD 1080P | YES | YES | YES |
| Intelligent split screen | YES | YES | YES |
| Time Switch | YES | YES | YES |
| Automatic Recognition | YES | YES | YES |
| Wifi network | NO | YES | YES |
| Remote control management | NO | YES | YES |
| APP installation | NO | YES | YES |
| Web surfing | NO | YES | YES |
| CPU | NO | RK3288 | Intel Celeron J1900/Intel Core i3/i5/i7 |
| RAM | NO | 2GB/4GB | 2GB/4GB/8GB |
| SSD | NO | 8GB/16GB/32GB | 64GB/128GB/256GB |
| Interface | HDMI | USB*2, Wifi, LAN, HDMI, VGA | USB2.0*2, USB3.0*2, HDMI*1, VGA*1 |
| Speaker | NO | 2*5W | 2*5W |
| CMS | NO | Yes, for free | Yes, for free |
| Multiple Language | English | Yes, could be your local language | Yes, could be your local language |
| Suitable for | Small amount of terminals that don`t require CMS | Interactive customer experience | Interactive information display with web browser |
