Basic Info.
Usage
Special Excavator, Marine Excavator, Mining Excavator
Transmission
Hydraulic Transmission
Drive Type
Internal Combustion Drive
Bucket Capacity
0.1~0.5m³
Certification
CE, ISO9001: 2000
Maximum Torque/Speed
70.3/1600n.M
Bucket Digging Force
23kN
Hydraulic Tank Capacity
22L
Max. Digging Height
4390mm
Specification
Operating weight
Production Capacity
10000 Units/Year
Product Description
Product Description
China Xuzhou Manufacture XE27U 2.7Ton Excavator with Good Price in Africa
The engine, which meets the national ll/ Euro V/ North American T4F emission standard, is energy economic and highly reliable; has strong green power and excellent performances.
The cab can meet the safety requirements of TOPS/ROPS/OPG through the optional front protection, which improves the driver's vision while ensuring the strength of the cab. The operator's seat is a mechanical suspension type imported from overseas, plus the standard and retractable safety belt, driver's safety is further guaranteed.
Sections of boom and arm that bear heavy stress are strengthened, and the whole parts are restructured to, resulting in disperse thed stress and increase thed service life. * Multiple lines can meet the needs of diversified tools including quick coupler.
Detailed Photos
Product Parameters
Description
| Unit
| XE27U
|
Operating weight
| Kg
| 2780
|
Bucket capacity
| m³
| 0.06
|
Engine
| Model
| /
| D1105
|
No. of cylinders
| /
| 3
|
Output power
| kw/rpm
| 15.6/2400
|
torque/speed
| N.m
| 70.3/(1600r/min)
|
Displacement
| L
| 1.123
|
Main Performance
| Travel speed(H/L)
| km/h
| 3.1/2
|
Gradeability
| °
| 30°
|
Ground pressure
| kPa
| 26.4
|
Bucket digging force
| kN
| 23
|
Arm croed force
| kN
| 14
|
Maximum traction
| kN
| 29.7
|
Oil Capacity
| Fuel tank capacity
| L
| 33
|
Hydraulic tank capacity
| L
| 22
|
Engine oil capacity
| L
| 5.1
|
Appearance size
| Overall length
| mm
| 4190
|
Overall width
| mm
| 1500
|
Overall height
| mm
| 2580
|
Width of platform
| mm
| 1350
|
Width of chassis
| mm
| 1500
|
Width of crawler
| mm
| 300
|
Track length on ground
| mm
| 1560
|
Crawler gauge
| mm
| 1300
|
Working Range
| Max. digging height
| mm
| 4390
|
Max. dumping height
| mm
| 3120
|
Max. digging depth
| mm
| 2800
|
Max. vertical wall digging depth
| mm
| 2310
|
Max. digging radius
| mm
| 4750
|
Min. swing radius
| mm
| 1980
|
