| Item | STBM5L1 |
| Bottle type specification | Cavity | 1 |
| Theory output | 700-800 |
| Max.volume | 5L |
| Bottle mouth maximum overall DIdiameter | 150mm |
| Bottle biggest diameter | 180mm |
| Bottle maximum height | 400mm |
| Power specifications | Light tube quantity | 32pcs |
| Light tube power | 1KW |
| Maximum heating power | 32KW |
| All electric machine installation | 35KW |
| Actual consumption | 24.5KW |
| Air pressure specification | Work pressure | 7-9kg/cm2 |
| Low-pressure gas consumption | 1200L/min |
| Blow bottle pressure | 25-35kg/cm2 |
| Higher -pressure gas consumption | 2000-2500Ltr/min |
| Forzen water specification | Work pressure | 5-6 kg/cm2 |
| Temperature range | 10ºC |
| Consumption | 4000kcal/hr |
| Forzen water flow | 30L/min |
