| Model
| Unit
| RC-2000-6
|
Molding group specification
| Number of modular cavities
| cavities
| 6
|
Bottle type specification
| Maximum bottle capacity
| ltr
| 2
|
Tooth size (outer diameter)
| mm
| 38
|
Maximum bottle diameter
| mm
| 110
|
Maximum body height
| mm
| 320
|
※Theoretical capacity
| B.P.H
| 7000
|
Power specifications
| Lamp Quantity
| pcs
| 40
|
Heating configuration power
| KW
| 80
|
Total power capacity
| KW
| 80
|
Actual power consumption
| KW
| 16
|
Voltage
| Voltage
| 220v/380V/3phase
|
Air compressor specification
| Operating pressure
| MPa
| 0.7-0.9
|
Blowing pressure
| MPa
| 3.5
|
Oxygen consumption of high pressure air
| L/min
| 3500
|
Cooling water specification
| temperature range
| °C
| 10
|
pressure
| Mpa
| 0.3-0.5
|
flow
| L/min
| 30
|
Machine
| Host size(L×W×H)
| M
| 5.5*2.1*2.2
|
machine weight
| KG
| 5000
|
