Product Details
Product Description
Product Description
Our Email: 2235954483@qq.com
contact number:13313705507
contacts：HE
Technical data of analog inputs
Number of channels per module, oper. mode"12 bits" 8
Number of channels per module, oper. mode "8 bits" up to 16
Configurability oper. mode "12 bits" ±10 V, 0...20 mA (each channel can be configured
individually)
Configurability oper. mode "8 bits" 0...10 V, 0...20 mA (channels can be configured in
pairs)
Signalization of input signals see diagnosis
Input resistance per channel voltage input > 100 kΩ
current input approx. 330 Ω
The current input has a self-protecting feature. If the current gets too high, the current input shunt is switched off and
the value for "overflow" is output. Re-activation is attempted again in increments of approx. 1 second to facilitate the
correct measurement as soon as the current regains acceptable limits.
Time constant of the input filter 470 µs for voltage,
100 µs for current
Conversion cycle (over 8 inputs + 8 outputs) 8 ms
Resolution range ±10 V oper. mode "12 bit" 5 mV (11 bit plus sign)
range 0...20 mA oper. mode "12 bit" 5 µA (12 bit without sign)
Resolution range 0...10 V oper. mode "8 bit" 40 mV (8 bit without sign)
range 0...20 mA oper. mode "8 bit" 80 µA (8 bit without sign)
Relationship between input signal and hexcode -100 %...0...100 % = 8008H...0000H...7FF8H
operating mode "12 bits" (-32760...0...32760 decimal)
Relationship between input signal and hexcode 0...100 % = 00H...FFH
operating mode "8 bits" (0...255 decimal)
Voltage inputs not used can be bridged to increase noise immunity
Current inputs not used are low in ohms, can remain open
Technical data of analog outputs
Number of channels per unit, oper. mode "12 bits" 8
Number of channels per unit, oper. mode "8 bits" up to 16
Configurability oper. mode "12 bits" ±10 V, 0...20 mA (each channel can be configured
individually)
Configurability oper. mode "8 bits" 0...10 V, 0...20 mA (channels can be configured in
pairs)
Signalization of output channels see diagnosis
Output loadability as voltage output max. +20 mA (source, current flows out of the
output)
max. -10 mA (sink, current flows into the output)
Output load resistance (burden), if current output 0...500 Ω
Resolution see "analog inputs"
Relationship between output signal and hexcode see "analog inputs"
Outputs not used remain open
>>
