| Max. swing over bed | 220mm |
| Max. swing over tool post | 115mm |
| Distance between centers | 550mm |
| Max.machining length | 520mm |
| Spindle taper | MT3 |
| Spindle bore | 20mm |
| Max. travel of tail-stock sleeve | 50mm |
| Taper of tail-stock | MT2 |
| Large carriage travel | 520mm |
| Middle carriage travel | 105mm |
| Small carriage travel | 70mm |
| Max. rotation angle of small carriage | 45° |
| Metric thread(Grade) | 0.25-3mm (17) |
| Inch thread(Grade) | 8-48T.P.I (17) |
| Longitudinal feed (Grade) | 0.04-0.2mm (5) |
| Spindle speed range(Grade) | 170-1950r/min(6) |
| Net weight | 130Kg |
| Overall dimensions | 1100*400*400mm |
| Packing Size | 1220*560*550mm |
