Turret Milling Machine X6325W Vertical and Horizontal Turret Milling Machine

US$4,300.00-4,500.00 1 Piece (MOQ)

Basic Info.

Model NO.
X6325W
Controlling Mode
Artificial
Automatic Grade
Manual
Precision
High Precision
Certification
GS, CE, RoHS, ISO 9001
Condition
New
Table Size
254X1270 / 254X1370mm
Longitudinal Travel
780 / 950mm
Transverse Travel
420 / 400mm
Vertical Travel
420mm
T Slot No. and Size
3X16mm
RAM Travel
470mm
Distance From Spindle Nose to Table Surf
0-405mm
Spindle Taper
R8,Optionl:ISO30/ISO40
Spindle Travel
127mm
Spindle Speed
(50Hz) 65-4500 16steps,Optional: (Variable)65-4500
Auto Quill Feed
0.04/0.08/0.15mm/Rev
Spindle Motor
2.2kw
Head Swivel
90°
Head Tilting
45°
Transport Package
Export Wooden CTN
Specification
1700 x 1510 x 2060mm
Trademark
JYME
Origin
China
Production Capacity
1000

Product Description


Product Application
The milling machine is a kind of universal light duty metal cutting machine,Has two functions of vertical and horizontal milling, Milling medium, small parts of the plane, inclined plane, groove and spline etc.. Widely used in mechanical processing, mold, equipment, instrumentation and other industries.
Technical specifications:
Specification
Unit
X6325W
Table size
mm
1270×254
Table travel (X/Y/Z)
mm
850×400×400
Spindle taper
Vertical spindle

R8/NT30

Horizontal spindle

NT40
Distance between horizontal nose and table surface
mm
0-400
Distance between spindle axis and ram surface
mm
270

Spindle speed range
Vertical spindle
Continuously variable speed

r/min
80-4200(Variable)


Variable speed

66-4540(16 steps)

Horizontal spindle

40-1300(12 steps)
T-lots(No./width/pitch)
mm
3/16/65
Ram travel
Tm
400
Main motor power
Vertical
HP
3kw

Horizontal

4kw
Overall size
mm
1600×1550×2150
Net weight
kg
1380

Machine Detials:
