| Item | Description |
| Max. Force | 2000 kg (20KN) |
| Load cell | 1 load cell for highest accuracy |
| Control system | Windows 7, RS-232 interface |
| Motor | Panasonic servo motor w/ DC variable speed drive system, high-precision mechanical ball screw rod |
| Force reading | kgf, Ibf, N, KN, T etc |
| Load cell Resolution | 1/250,000 |
| Load Precision | within ±0.25% |
| Parallelism of Platens | Parallel within ±2.5mm |
| Effective test area | 800*800*800MM |
| Test speed | 10 ±3mm/min (0.01~200mm/min adjustable) |
| Software | TM 2101 |
| Data display | Load, displacement, speed, loading rate and elapsed time |
| Safety features | E-Stop Over-load protection Upper and lower limit switches Load sensor with automatic retreat |
