| US$350.00-650.00 | 1 Piece (MOQ) |
| Specification | ||
| Weight | 24 | kg |
| Outside dimensions(L×W×H) | 605*485*158 | mm |
| Cylinder diameter | 82 | mm |
| Piston Stroke | 60 | mm |
| Working Pressure | 0.40-0.63 | mpa |
| Impact Energy | J | |
| ≥78(0.63Mpa) | ||
| ≥69(0.5Mpa) | ||
| ≥50(0.4Mpa) | ||
| Air Consumption | L/S | |
| ≤88(0.63Mpa) | ||
| ≤65(0.5Mpa) | ||
| ≤53(0.4Mpa) | ||
| Impact Frequency | HZ | |
| ≥39(0.63Mpa) | ||
| ≥37(0.5Mpa) | ||
| ≥26(0.4Mpa) | ||
| Torque | N.M | |
| ≥20(0.63Mpa) | ||
| ≥17(0.5Mpa) | ||
| ≥15(0.4Mpa) | ||
| Rotated speed | 300(0.5Mpa) | R/min |
| Working Water Pressure | 0.3 | Mpa |
| Air pipe inner diameter | 25 | mm |
| Water pipe inner diameter | 13 | mm |
| Rock drill hole diameter | 34-42 | mm |
| Max drilling depth | 5 | m |
| Working temperature | 30~45 | ºC |
| Shank Size | H22*108 | mm |
| FY250 Oil Lubricator | ||
| Weight | 1.2 | kg |
| Oil Reserve | 0.25 | Litre |
| FT160A Air Leg | ||
| Length | 1668 | mm |
| Advance Length | 1338 | mm |
| Cylinder diameter | 65 | mm |
| Weight | 18 | kg |
