25-240cbm/H Rmc Precast Concrete Batching/Mixing Plant for Sale

Product Description

25-240cbm/H Premix Rmc Concrete Batching/Mixing Plant for Sale
We can supply large range sizes of Stationary RMC Concrete Batching Plant/Concrete Mixing Plant:
Hoist Bucket Type (Compact structure, save space, low cost):
HZS25 25cbm/h, HZS35 35cbm/h, HZS50 50cbm/h, HZS75 75cbm/h
Belt Conveyor Type (High working efficiency, high production capacity, large space, high cost):
HZS60 60cbm/h, HZS90 90cbm/h, HZS120 120cbm/h, HZS180 180cbm/h
HZS Series wet mix Stationary RMC Concrete Batching Plant/Concrete Mixing Plant:
HZS Series ready mixed concrete mixing plant is composed of material supply batching system, mixing electrical control and steel structure. It is ideal concrete batching equipment for building project, building ground and precast product factory.
Main characteristics of FOCUS Stationary RMC Concrete Batching Plant/Concrete Mixing Plant:
1. It adopts knock down structure and blocking. It is combine concrete batching plant mode.
2. The machine adopts twin shaft concrete mixer, it has good concrete mixing quality and high efficiency.
3. The batching machine is measuring well and high produce efficiency.
4. The forced water supply system of concrete batching plant spray equably and has washing function for the concrete mixing system.
Details of FOCUS Stationary RMC Concrete Batching Plant/Concrete Mixing Plant:
Hoist bucket type(Save place, low cost):
HZS25 25cbm/h, HZS35 35cbm/h, HZS50 50cbm/h, HZS75 75cbm/h
Parameters of Hoist bucket type RMC Concrete Batching Plant/Concrete Mixing Plant:

Model	HZS25	HZS35	HZS50	HZS75
Theoretical output(m³/h)	25	35	50	75
Mixer model	JS500	JS750	JS1000	JS1500
Output per batch(m³)	0.5	0.75	1	1.5
Aggregate batcher	PLD800	PLD1200	PLD1600	PLD2400
Total power(KW)	27	35	80	110
Aggregate weighing accuracy(%)	(0-1500)kg±2%	(0-2250) kg±2%	(0-2500)kg±2%	(0-4000) kg±2%
cement weighing accuracy(%)	(0-300)kg±1%	(0-400)kg±1%	(0-500) kg±1%	(0-800) kg±1%
water weighing accuracy(%)	(0-200)kg±1%	(0-300)kg±1%	(0-300)kg±1%	(0-500)kg±1%
fly ash weighing accuracy(%)	(0-300)kg±1%	(0-300)kg±1%	(0-300)kg±1%	(0-500)kg±1%
additive weighing accuracy(%)	(0-40)kg±1%	(0-40)kg±1%	(0-40)kg±1%	(0-50)kg±1%
Discharge height(m)	3.8-4.1
Max. aggregate dia.(mm)	60	60	80		80
Cement silo and screw conveyor	On request
Total weight (ton)	20	25	35	45
Overall dimension(LxWxH)(m)	11.5x5.8x19.4	12x6x19.4	20.5x7.5x19.4	25.9x9.2x19.4

Belt Conveyor type(High production capacity, high cost):
HZS60 60cbm/h, HZS90 90cbm/h, HZS120 120cbm/h, HZS180 180cbm/h
Parameters of Belt conveyor type RMC Concrete Batching Plant/Concrete Mixing Plant:

Model	HZS60	HZS90	HZS120	HZS180	HZS240
Theoretical output(m³/h)	60	90	120	180	240
Mixer model	JS1000	JS1500	JS2000	JS3000	JS4000
Output per batch(m³)	1	1.5	2	3	4
Aggregate batcher	PLD2400	PLD2400	PLD3200	PLD4800	PLD6400
Total power(KW)	110	145	160	205	340
Aggregate weighing accuracy(%)	(0-3000)kg±2%	(0-4000)kg±2%	(0-4500)kg±2%	(0-4500)kg±2%	(0-6000)kg±2%
cement weighing accuracy(%)	(0-600)kg±1%	(0-1000)kg±1%	(0-1200)kg±1%	(0-1800)kg±1%	(0-2400)kg±1%
water weighing accuracy(%)	(0-400)kg±1%	(0-400)kg±1%	(0-600)kg±1%	(0-800)kg±1%	(0-1000)kg±1%
fly ash weighing accuracy(%)	(0-400)kg±1%	(0-400)kg±1%	(0-600)kg±1%	(0-800)kg±1%	(0-700)kg±1%
additive weighing accuracy(%)	(0-40)kg±1%	(0-40)kg±1%	(0-50)kg±1%	(0-50)kg±1%	(0-120)kg±1%
Discharge height(m)	3.8-4.2
Max. aggregate dia.(mm)	80-100
Cement silo and screw conveyor	On request
Total weight (ton)	46	60	71	87	112
Overall dimension(LxWxH)(m)	33.8x14.8x19.4	38x16x19.4	44x18x19.4	58.5x23.5x22	60x25x22

CE Certificate of FOCUS Stationary RMC Concrete Batching Plant/Concrete Mixing Plant:

---
