| US$60,000.00-75,000.00 | 1 Set (MOQ) |
| Feeding type | Feeding by gravity |
| Weighing Range(kg) | 5-25kg |
| Structural Features | Cylinder type,three sensor |
| Suitable Material | granule |
| Weighing Precision | ±0.1%~±0.2% |
| Packing Speed(bag/h) | 400-700 |
| Form | TN-s |
| Air Pressure | 0.5-0.7Mpa |
| Total Air Consumption | 9m³/h |
| Total Power Consumption | AC380V±10% 50Hz three-phase five-wire system 6kw |
| Environment Temperature | 0-40ºC |
| Ambient humidity | Less than 90%RH at 40ºC,higher humidity is permitted at lower temperature |
| Dimension(mm) L*W*H | 5500*3800*3200 |
| No | Item Name | Item Brand | Type |
| 1 | PLC | Omron(Japan) | Electro Part |
| 2 | Touch Screen | Delta(Taiwan) | |
| 3 | Frequency Converter | Eaton(Germany) | |
| 4 | Low voltage electrical | Eaton(Germany) | |
| 5 | Limit switch | Omron(Japan) | |
| 6 | Photoelectric / proximity switch | Turck(Germany) | |
| 7 | Vacuum pressure switch | SMC(Japan) | |
| 8 | Load cell | Mettle Toledo(USA) | |
| 9 | Relay | IDEC(Japan) | |
| 11 | Vacuum chuck | Patents special | Mechanical Part |
| 12 | Vacuum pumb | Zhongde(China) | |
| 13 | Cylinder | Airtag | |
| 14 | Electromagnetic valve | SMC(Japan) | |
| 15 | Ordinary motor | Zhenyu(China) | |
| 16 | servo motor | Delta(Taiwan) | |
| 17 | Planetary reducer | Delta(Taiwan) | |
| 18 | Rack and pinion | Made in China |
