Model
| SS-SP18W
|
Peak power Pm(W)
| 18±3%
|
Solar pannel cell/ efficiency
| Sunpower/22-24%
|
Solar panel front cover(material/thickness)
| Frosted PET/0.2mm
|
Encapsulant(material)
| Ethylene vinyl acetate(EVA)
|
Solar panel back material
| glass fiber PCB1.2mm/TPT0.2mm
|
Leather/ Color
| 0.8mm thickness PU leather /orange
|
Open circuit voltage Voc(V)
| 7.2
|
Max. power voltage Vmp(V)
| 6
|
Max. power current Imp(A)
| 3.6
|
Solar pannel size(MM)
| 270*180*2
|
Solar pannel power(W)
| 9
|
Solar pannel number(pcs)
| 2
|
Folding size/open size/weight
| 285*195*25mm/285*496*5mm/0.34 kg
|
Output port
| USB1+USB2
|
Output voltage
| 5V3.6A
|
Junction box protection degree
| ≥IP65
|
STC
| Irradiance:1000W/m2,Cell temperature:25ºC,AM:1.5
|
