Wood Log Debarker and Chipping Line for Paper Mills

Product Description

Debarker + wood chipper + screen line layout:(making wood chip for paper pulp mills)
Our Wood peeling machine has strong adaptability to wood, for different tree species, diameter, length and shape of wood segment peeling, suitable for small and medium-sized paper mills, pulp mills, wood chip factories, wood processing plants, forest plants, lumber yard, wood-based board factories, etc.
Debarker Parameters:

Model	HX630	HX850	HX1020
Applied wood log diameter	5cm-45cm	15cm-55cm	20cm-75cm
Capacity per hour	15-25tons	20-30 tons	30-50 tons
Roller diameter	630mm	850mm	1020mm
Debarking rate	>98%	>98%	>98%
Main motor power	45KW	55KW	75KW
Roller length	11m	11m	11m
Roller rotation speed	65r/min	61r/min	55r/min
Machine size(m)	11.5*2.2*2.63	11.5*2.4*2.73	11.5*2.65*3.3

Disc wood chipper parameters:

Model	HX1710	HX1300	HX1216	HX1800
Rotation speed(rpm)	635	650	620	420
Blade QTY(piece)	6	6	6	6
Chip size(mm)	20-35	20-35	20-35	20-35
Input size(mm)	270x270	350x350	420x420	500x500
capacity(TPH)	5-10	10-15	15-25	20-40
Main power(kw)	55	90	132	160
Feed + discharge motor (kw)	3+3	3+3	3+3	5.5+5.5
Disc diameter (mm)	1150	1300	1600	1800
Weight (t)	2.8	3.6	6.58	7.5
Feed conveyor width (mm)	350	350	470	550
Feed conveyor length (mm)	4000	4000	6000	6000
Discharge conveyor width (mm)	600	600	900	1300
Discharge conveyor length (mm)	10000	10000	10000	10000

Screen parameters:

Model	layer quantity	Main motor	Shaft rotation	size	Mesh size(mm)
Virbation screen-A	3	3KW	175rpm	(1.6m-2.5m)*(2m-4m ) or customized	customized
Vibration screen-B	3	5KW	150rpm	(2.5m-3.5m)*(1.5m-2m) or customized	customized
Drum rotation screen	1 or 2 or 3	5.5KW -21KW	20-30rpm	1.6m diameter *(4m-6m length) or customized	customized

Working site
Screen:
Manufacture
Clients visiting
Our Mill
Certificate:

---
