Basic Info.
Application
Cotton, Rice, Corn, Fruit, Wheat, Soybean, Tubers, Straw
Portable Harvester Type
Side Hanging Type
Certification
QS, GMP, ISO9001:2008, CE
Application Field
Agriculture, Livestock, Aquaculture, Forestry
Total Loss Rate (%)
Wheat:1.2 Rice:3.0
Broken Rate (%)
Wheat:1.0 Rice:1.5
Impurity Rate (%)
Wheat:2.0 Rice:2.0
Grain Tank Capacity(M³)
2.3
Running Speed Range(Km/H)
1.3-2.0
Overall Dimension (L*W*H) (mm)
6950*3250*3400
Grain Unloading Type
Mechanical Grain Discharging Hopper
Transport Package
Roro/Nude Packing by Contianer/Bulk
Specification
6950*3250*3400 MM
Production Capacity
100 Units/ Month
Product Description
Mini Wheat Harvester Walking Corn Harvester Betel Nut Harvester
Product Description
1. Adopt new structure strengthened drive axle.
2. The space on sheller concaved plate can be adjusted rapidly.
3. Adopt secondary shelling technique by surplus crop recycling sleeve.
4. Cleaning unit adopts axial and radial double inlet fan. This new type is equipped with a widen cleaning screener.
5. LCD rotating speed instrument, alarm system for component blogging and full grain, which is of high leveled automation.
6. Choosable high rib tires, and the distance between back wheels can be adjusted.
7. Choosable displacement with special accessories for harvest of rice, soybean, rape, etc.
8. Choosbale straw choosing machine to satisfy the requirement of straw recycling.
Specification
Engine power (ps) | 90,100 |
Cutting width (mm) | 2500,2750, |
Feeding rate (kg/s) | 2.8 |
Total loss rate (%) | Wheat ≤1.2 Rice≤3.0 |
Broken rate (%) | Wheat≤1.0 Rice≤1.5 |
Impurity rate (%) | Wheat≤2.0 Rice≤2.0 |
Threshing and cleaning structure type | Slip Flow + Horizontal Spindle + Centrifugal Fan + Double Layers Vibrating Screener |
Gravure plate adjustable structure | Mechanical Controlled Adjustable Speed at Definite Ratios |
Axis flow roller(outer diameter*length) | φ560*820 |
Grain tank capacity(m³) | 2.3 |
Grain unloading type | Mechanical Grain Discharging Hopper;Choosable Grain Discharging Sleeve |
Running speed range(Km/h) | 1.3~20 |
Operation weight | 5100 |
Overall dimension (L*W*H) (mm) | 6950*3250*3400 (Assembled with 2.75m shear platform) |
