New Design Jumbo Roll A4 Writing Paper Production Line Newspaper Making Machine with Best Price

Product Description

New Design Jumbo Roll A4 Writing Paper Production Line Newspaper Making Machine with Best Price Product Description Cultural paper machine mainly uses waste paper and wood pulp as raw materials to produce cultural paper, book paper and other common paper. It mainly has the following characteristics:
1) Reliable quality, stable performance, convenient operation, energy conservation, environmental protection.
2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.
3) It is made up of molding, drying, transmission, pressing, walking platform and reeling parts.
4) Running in a high automatization and intellectualization.
5) Computer PLC control system with easy operation.


Product Parameters

Raw material	Waste paper,waste carton paper
Finished paper	Newspaper,cultural paper,writing paper
Paper width	3200mm
Paper weigth	40-180g/m2
Capacity	30-40T/D
Design speed	300m/min
Working speed	200-250m/min
Drive way	AC frequency conversion,section drive

Detailed Photos 1.Headbox & Wire Section:
(1) Fourdrinier table length is usually between 13m and 24m.(decided by working speed).
(2) It can select open-type headbox when the working speed is less than the 250m/min;
(3 )Select the air-cushioned headbox when the working speed is more than 250m/min.
(4)The dewatering components are usually uses the stainless steel vacuum suction box. Full ceramic girder or inserted ceramic girder.
2.Press Section: (1) The press consists of a vacuum suction device, four rollers twin press and one main press. (2) Four rollers twin press specially suit for making newsprinting paper,culture paper and writing paper. (3 )The main press can improve press nip width dewatering wet sheet strength and finished paper density.
3. Drying Section: (1) It usually uses several dryer cylinder groups with the diameter of Φ1500mm or Φ1800mm. drive: closed gear box each dryer group single drive or single gear box each dryer group multi-points drive. (2) When wet paper enters into dryer section, it can select different leading way and paper orientation according to PM working speed, production basis weight and pulp impurity. (3) The wetting size can increase about 180% finished paper ring crush index.
4.Calendering Section
The calender is used to improve the gloss, smoothness and tightness of the paper, reduce the air permeability and obtain the paper with uniform thickness.
Company Profile Qinyang shilong paper machinery factory is a high-tech enterprise integrating design, production and sales, specializing in the production of paper machinery and pulping equipment. It mainly produces paper machines and papermaking equipment, and can produce various specifications of toilet paper machines, corrugated paper machines, cultural paper writing paper machines, kraft paper machines, garden net paper machines, long net paper machines and stacked net paper machines.
Certifications

Packaging & Shipping
Cooperative customers
Q: 1.What information do you need,if i need to get a quotation from you?
A: Output paper type;Capacity(tons/24hours);Output paper weight(gram/m2);Raw material
Q: 2.What is the delivery time if we make a order from you?
A: Usually, the delivery time for smaller machines is 30-45 days after receiving deposit,But for bigger machines, it will be longer to make sure the equipment quality.
Q: 3.Why your price is higher than other similar supplier?
A: Different quality, different price.Our price is matched with our high quality.Compared with to her supplier based on the same quality,our price is lower.But anyway,to show our sincerity, we will give you some some discount.
Q:4.How we visit your fatory and what will be the proedure?
A: Our company located in Qinyang city, henan province, if you take plane, it will need about 2 hours from Guangzhou city, 1.5 hours from Shanghai city and 1 hour from Beijing city. We will pick you up from Zhengzhou airport or the train station. We will take you to see our machine running in our chinese clients' paper mill. Welcome you and your team to visit our company.

---
