15 M3 Concrete Mixer with Delivery Pump (CPM15)

Product Description

Mobile Concrete Mixing Pump CPM15 for concrete pumping works
Specifications:

Item	Unit	Specificaiton
Max. Actual Output	m3/h	15
Max.Theoretical Output	m3/h	30
Max.Outlet Pressure	Mpa	10
Distribution Valve Type		S Tube Valve
Concrete Clinder Size	mm	φ160×1000
Main Oil Cylinder	mm	φ110/1000
Oil Tank Capacity	L	200
Inner Dia.of Delivery Pipe	mm	φ125
Power		45kw
Max. Dia of Aggregates	mm	40
Towing Speed	km/h	≤8
Max.Horizontal Distance	m	200
Max.Vertical Distance	m	40
Mixer Model	RDCM350
Unmixed Capacity	L	560L
Mixed Capacity	L	350L
Drum Capacity	L	2210
Drum Thickness	mm	5
Drum Speed	rpm	15
Hopper Lifter	s	6
Loading Hopper		Mechanical Hoist Hopper
Mixing Time	s	45~60
Overall Size	mm	5300×2090×3600
Weight	kg	4000

Description
CPM15 Concrete Pump and Mixer mixing conveyer has agitation and the transportation
functions. The agitation system adopts self-fall type bi-pyramid to reverse discharging
mechanism; The hydraulic system uses double cylinder piston type, the electrical and
hydraulic control, the S valve assignment form.
Main parts:
1.The main engine is composed by the hydraulic system, the electric system, the pump
system, the mixing mechanism, the distributing valve, the running gear, the cowling, the
rack, the transfer pipeline and so on.
2.The hydraulic system is composed by the main oil route system, the distributing valve oil system, the mixing oil system.
3.Main main oil route system including oil filter, ram pump, Electromagnetism distributing
valve, electromagnetism overflow valve, check valve, main oil cylinder as well as pipeline
appendix.
4.The distributing valve oil system including oil filter, Electromagnetism distributing valve,
oil cylinder as well as pipeline appendix and so on.
5.The electric system including the electromotor, AC contact device, air switch, push-button switch.
Advantages
This equipment has the system to be stable, the control system is simple, the control is
convenient, few maintenance, motion convenience and so on
Features
1. It may use to the high-rise construction or the remote transfer mortar, the foaming
concretes as well as the small aggregate concretes, facilitates the construction work. It
has the transportation, the efficiency high, to disturb slightly mutually continuously with
other equipment, it may transport the mortar to the other equipment out of reach place.
Mortar flows in the pipeline, it will not cause merits environmental pollution and so on.
2. It through increased the compressed air injection gear to constitute a complete wet
concretes jet aircraft, it might use in the mine pit and the understructure work supports
and protections lining work. The construction wall surface spray coating, the construction
structure reinforcement, the ground side slope stability, projects tunnel excavation and so on. It has the work efficiency to be high, the concretes quality is good, the dust loading is
low, the snapping back rate is low, the failure rate is low, and the building cost of projects
is low.
1. Agitation system
(1)It uses self-falls bi-pyramid and reverse discharge mechanism, the production
efficiency is high, the agitation quality is good;
(2)Stirs drum uses the gear transmission, the transmission efficiency is high, the failure
rate is low, and maintains is simply.
2. Hydraulic system
(1)The operating valve uses the advanced S valve, the leak-proof quality is good,
structure is simple and reliable. The eyeglasses board and the wear resisting link
use the hard alloy, the resistance to wear are good, the life is long, the replacement is
convenient, the wear-resisting link uses may the automatic compensation
gap organization;
(2)The control mode uses electricity - hydraulic control, the operation is simple, the
revolution is steady, the noise is low; It has the consummation electricity - fluid over-load protection and the measuring appliance display system; it has the reverse-pump operation function; It is safely reliable, easy to fix the jamming breakdown; Services
conveniently;
(3)Contact device and push-button switch electric appliance modules and so on,
the protection rank may achieve IP65, the control wiring is simple, operation reliable;
(4)It is suitability to many kinds of mortar, like spraying mortar, wall surface mortar, ground mortar, small aggregate concretes and so on.

---
