Product Details
Product Description
Product Description
Tension measuring instruments are divided into IP20 and IP65 protection levels. They are selected according to the installation environment. The models are pfel111, pfel112 and pfel113
Pfel111: no DP interface, capable of connecting 2 indenters
Pfel112: with DP interface, capable of connecting 2 indenters
Pfel113: with DP interface, can connect 4 indenters
1. Model: pfea111
Description: the conventional control unit can connect two indenters. According to the different application environment, it has IP20 and IP65 protection levels. The PLC interface signal is 0-10V DC. Various calibration and range parameters can be set on site.
2. Model: pfcl201c
Description: pillow block tensiometer is a vertical load cell connected by cylindrical plug; Force measuring range: 5 ~ 50kN;
3. Model: pfcl201cd / CE
Description: vertical load cell of pillow block tensiometer is connected by cable sealing joint / fixed cable with protective hose, and the measuring range is 5 ~ 50kN;
4. Model: pftl101a
Description: horizontal load cell of pillow block tensiometer, connected with cylindrical plug, with force measuring range of 0.2 ~ 2Kn
5. Model: pftl101ae
Description: pillow block tensiometer horizontal load cell, fixed cable connection, force measuring range: 0.2 ~ 2Kn
6. Model: pftl101aer
Description: acid resistant pillow block type tensiometer horizontal load cell, fixed cable connection, force measuring range: 0.2 ~ 2Kn It is used for measuring the tension at the wet end of paper making, and the protection grade can reach IP66 / 67
7. Model: pftl101b
Description: horizontal load cell of pillow block type tensiometer, connected by cylindrical plug, with force measuring range of 2 ~ 20KN
8. Model: pftl101be
Description: horizontal load cell of pillow block tensiometer, fixed cable connection, force measuring range: 2 ~ 20KN
9. Model: pftl101ber
Description: acid resistant pillow block type tensiometer horizontal load cell, fixed cable connection, force measuring range: 2 ~ 20KN It is used for measuring the tension at the wet end of paper making, and the protection grade can reach IP66 / 67
10. Model: pftl201c
Description: horizontal load cell of pillow block type tensiometer, connected by cylindrical plug, with force measuring range of 10 ~ 50kN
11. Model: pfcl301e
Description: Mini paper web tension vertical load cell, load range: 0.2 ~ 1kn
12. Model: pftl301e
Description: mini type paper web tension horizontal load cell, load range: 0.1 ~ 1kn
13. Model: pfrl101d
Description: radial load cell, rated load 5.0kn
14. Model: pfrl101c
Description: radial load cell, rated load 0.5 ~ 2.0kn
15. Model: pfrl101b
Description: radial load cell, rated load 1.0kn
16. Model: pfrl101a
Description: radial load cell, rated load 0.5kn
17. Model: pfea113
Description: tension controller, with four load cells, PROFIBUS DP field bus communication function and six configurable analog output ports.
18. Model: pfea112
Description: PROFIBUS DP field bus communication function is added on the basis of PFEA 111.
19. Model: pfea111
Description: tension controller, with two load cells, compact structure and guide rail installation.
20. Model: pftl201ce
Description: pillow block tensiometer horizontal load cell, fixed cable connection, force measuring range: 10 ~ 50kN
21. Model: pftl201d
Description: horizontal load cell of pillow block type tensiometer, connected by cylindrical plug, with force measuring range of 50 ~ 100kN
22. Model: pftl201de
Description: pillow block tensiometer horizontal load cell, fixed cable connection, force measuring range: 50 ~ 100kN
23. Model: pfvl141v
Description: rectangular load cell, force measuring range: 0.63 ~ 56Mn; Width range: 70 ~ 610mm; Length range: 120 ~ 1320mm height: 74mm.
24. Model: pfvl141c
Description: circular load cell PFVL 141C, force measuring range: 1.6 ~ 60Mn; Diameter range: 210 ~ 890mm; Height: 74mm.
25. Model: pfvl141r
Description: annular load cell PFVL 141r, measuring range: 2 ~ 28mn; Outer diameter range: 240 ~ 895mm; Inner diameter range: 100 ~ 595mm height: 74mm
26. Model: pxah401
Description: millmate operator unit 400, panel mounted, can communicate with the control unit network. Size: 160 × two hundred and thirty-five ×? 60 mm, front protection grade IP65, other directions IP20, weight: 1.3 kg
27. Model: pfva401
Description: rolling force controller, which can provide excitation to load cell, with analog input / output, digital input / output, Ethernet interface, RS232 / 485 interface, optional high-speed field bus communication interface.
28. Model: pfbl141b / C
Description: the vertical force test unit is divided into single roller / double roller and fixed / rotating shaft end. The measurement range is 4 - 400 kn. The overall dimensions of pfbl 141C can be customized according to user requirements.
29. Model: pfea101
Description: constant tension closed-loop control is carried out during uncoiling and coiling. Load cells and torque output devices such as brakes, clutches and motors can be connected.
>>
