300kg/H Vibrating Sieve Type Animal Feed Pellet Cooling Machine

Product Description

Horizontal Wood Pellet Cooler, Feed Pellet Cooling Machine
Introduction of Pellet Cooler:
This feed pellet cooler is base on the drum of rotary sieve which is made up of drum sieve and frame. There is one certain degree between the rotary drum sieve and ground. The outside of the sieve is covered by closed steel to reduce the noisy pollution. On the adjustable speed system, the drum sieve is rotating on certain speed; the pellet is separated and cooled from top to bottom on the rotating of drum sieve.
The fine powder is discharged from the front of drum sieve, and the good pellet is outlet from the back of drum sieve. During the cooling and sieving process, the rotating is evenly, low impulsion and vibrating, and stable. The installation this machine is easy which can be directly put on the ground, floor board or under the storage. This machine is easy to closely collect dust and maintain.
Technical parameter of pellet cooler:

Model	LQJ-500	LQJ-1000	LQJ-1500
Power	1.5+4kw	2.2+5.5kw	4+7.5kw
Capacity	500 Kg/h	1000 Kg/h	1500 Kg/h
Dimension	1200*900*1300mm	1500*1100*1500mm	2300*1600*1600mm
Weight	200Kg	260Kg	350Kg
Function	Cooling and Screening
Cooling type	Fan type;
Dedusting	dust-collector

Features of Pellet Cooling Machine:
1) Large cooling room and cooling capacity from 5-30t/h.
2) Countercurrent cooling principle, reasonable design, good cooling effect.
3) Cold air enters from the bottom ensures high cold air efficiency.
4) Unique rotating structure to distribute pellets evenly, complete cooling
5) Suitable to cool bulk, platy or particles materials, especially to puffing materials and other large volume material.
Remarks:
1. Payment: T/T; L/C; PayPal...
2. Warranty: one year except spare parts
3. Package: wooden case
4. Delivery time: within 7-10 days against the down payment

---
