| US$700.00 | 1 Piece (MOQ) |
| Serial number | Test item | Performance Index | Remarks |
| 1 | working frequency | 5725-5850MHz | |
| 2 | Output power | ≥ 100W(@ 28V) | |
| 3 | working current | ≤ 9A(28V) | |
| 4 | Working temperature | -25 ºC ~ 85 ºC | |
| 5 | Port Impedance | 50Ω | |
| 6 | Output standing wave ratio | ≤ 2 | |
| 7 | Working voltage | (+24V ~ +30V) | |
| 8 | Anti-vibration | Have anti-vibration requirements | design guarantee. |
| 9 | dimensions | See detailed design drawing | mm |
| 10 | power amplifier switch | VCC level on, low level | optional |
| 11 | Source | VCO | built-in |
