Factory Supply 100% Original XP600 I3200 Printhead for Epson

Product Description

Type	PrecisionCore MicroTFP printhead
Width*Depth*Height	69.1x 59.4 x 35.6 mm
Weight	82 g
Number of nozzle	3200
Nozzle pitch/nozzle row	1/300 inch
Nozzle rows	8 rows
Nozzle Resolution	300 npi /row 600 npi/2 row
Max. number of colour inks	4 colours
Effective print width	PrecisionCore 33.8 mm (1.33 inches)
Jetting frequency	43.2 kHz (Single mode)	21.6 kHz (Multi mode)
Droplet volumes	5 pl (Single mode)	6 pl (Single mode)
	6, 12.5 pl (Multi mode)	6.3,1 2.3 pl (Multi mode)
Viscosity range	5-7 mPa.s	3-4 mPa.s
Positioning Mechanism	Reference hole

1.PrecisionCore Technology a. All MEMS manufacturing and thin film piezo element can realize high precision and high density(600 npi / 2 rows of nozzles).Contributes to compact, high speed, high quality, and high image quality.b. Precision made of Epson unique MEMS nozzles and an ink flow path ensure the per fectly round ink droplets are placed accurately and consistently.

Title goes here. With Epson's unique Variable Sized Droplet Technology (VSDT) delivers smooth gradation by freely control to eject the droplet volume.

3. High resolution Ink ejection of up to 4 colours realize with high resolution (600 dpi/colour). In addition to the I3200, I1600 has also been added to the lineup in order to meet the various customer needs.

4. High durability PrecisionCore print head has proven high durability and extended service life by Epson's industrial printers.

Nozzle blocking prevention 1,the cloth is paved, the height of the nozzle is confirmed, do not scrape the cloth! Otherwise, the nozzle is easily damaged 2, finish the goods every day, make sure that the test strip is no problem and then shut down, the test strip is sent to the corresponding after-sales group, and be sure to clean out the day of blockage! White ink ink pad dailymoisturizer, do not allow water and alcohol 3, when the machine does not do goods for more than 24 hours, the machine needs to be started for 30 minutes, and the test bar to confirm the status of the nozzle 4. If the machine does not do goods for a long time, please operate according to the nozzle maintenance standard. If in doubt, contact the corresponding after-sales service in time 5.Clean the ink pad and scraper every day to avoid clumping and damaging the nozzle 6, ink bag, filter must be replaced once every three months, ink pot cleaning once every three months 7, indoor temperature: 15ºC ~ 28ºC, humidity: 65%, otherwise easy to block the nozzle 8, white ink ink do not replace at will, otherwise affect the fastness and blocking nozzle, can not be after-sales.
FAQ 1.Q:With color ink and white ink printer, do not need to use manual printing board?
A:No need,a digital high-definition image printing, dark fabric can also be achieved
2.Q:What kind of fabric can this machine print?
A:It can be printed Cotton, linen, jeans, real silk(Cutting piece,Finished clothes).
3.Q:What industry is this machine suitable for?
A:Can meet personalized flower customization, clothing, screen printing, embroidery, fashion design room, hand-painted workshop.
4. Q: if I want to buy a machine, what kind of service will I get?
A: When you buy our machine, we will provide you with all-weather door-to-door service. If you can't provide door-to-door service because of some irresistible circumstances, we will solve your problems by online video, telephone and video tutorial.

---
