Fp6400 Professional Power Amplifier Audio, Digital Stereo AMPS

Product Description

20-20kHz, 1W with 1 kHz Output Power, High Efficiency Switching Audio Amplifier ( FP6400)
High Efficiency Amplifier (FP6400)
1. 2X1300W@8 ohms Switch Model Power Amplifier
2. FP6400 Switching Mode Amplifier Professional Audio
3. 13kg Net Weight Switch Mode Amplifier
KEY FEATURE
1). Switching power supply
High efficiency and stability of the new switching power supply so that the signal transmission speed faster and more stable voltage changes, sensitivity stronger, lighter weight.
2). Intelligent signal limiter
Each channel has an independent output signal overload distortion, automatic pressure limited function, when the output signals are now clipping distortion can be quickly restored to the output signal compression is not the biggest distortion level and no reduction in the frequency response of audio signals, to avoid DC level because of the audio signal output and burned speakers.
3). Multiple detection, multiple protection
A soft start, the second start, the (low) pressure protection, output overload and short circuit protection.
4). High efficiency, low fever
Efficient Class TD amplifier, significantly reduce heat loss.
5). Pristine audio
Metal Packaging, high-power transistors, Yanyi a pure, passionate, authentic audio effects.
6). Removable face Network
Removable the hole into the wind-net, easy cleaning.
Specifications:

High Efficiency Power Amplifier Audio FP6400
ITEM	fp6400
Output Power	20-20kHz, 1W with 1 khz
8ΩStereo Power(RMS)	1300W ×2
4ΩStereo Power(RMS)	2300W ×2
2ΩStereo Power(RMS)	2900W ×2
8ΩBridged Power(RMS)	4600W
4ΩBridged Power(RMS)	5800W
Frequency Response (+o/-0.3dB, 1W/8Ω)	20-20KHz±0.5dB
THD+N:10KHZ<0.05%	10KHZ<0.05%
Signal-to-Noise	<-110dB
Slew Rate	20V/us
Input Connectors (per channel)	Female XLR (pin 2+, configurable for pin 3+). TRS (tip+)
Output Connectors (per channel)	5-way binding posts or Speakon connectors (market dependent)
Class	TD
TourClass Protection	ACL, IGM, AutoRamp, short circuit, DC voltage, turn-on/off transient, current inrush, sub/ultrasonic input
Voltage Gain(dB)	20 23 26 29 32 35 38 41 seletable
Cooling	4pcs variable speed DC fans, better than conventional cooling
Controls	Front panel: 2 attenuators, power switch; Rear panel: signal ground lift & mode switches
Dimensions (W×H×D)	483×88×347mm
Packing dimension	575×140×550mm
Net weight(kg)	13
Gross weight(kg)	17

---
