| Model | Model SYM5300THBFS 430C-10 |
| Length(mm) | 11500 |
| Width(mm) | 2550 |
| Height(mm) | 3970 |
| Dead Weight(kg) | 29000 |
| Vertical Reach(m) | 43 |
| Horizontal Reach(m) | 38 |
| Reach Depth(m) | 27 |
| Min. Unfolded Reach(m) | 11 |
| Delivery Cylinder Diameter(mm) | 230 |
| Stroke Length(mm) | 1600 |
| Hydraulic System | OPEN |
| Hydraulic System Oil Pressure(MPa) | 32 |
| Oil Tank Capacity(L) | 320 |
| Water Tank Capacity(L) | 700 |
| Pipe Diameter(mm) | 125 |
| Chassis Model | SYM5330THB1F |
| Engine Type | D09C6-340E0 |
| Engine Maximum Net Power(kW/rpm) | 244/1900 |
| Fuel Tank Capacity(L) | 300 |
