Innovative New Materials Testing Machine with High Precision Capillary Rheometer

Product Description

Product Description
Capillary Rheometer MLW-400D Application area 1. Our state-of-the-art machine is expertly crafted to comply with the 'capillary' segment of ISO 11443 'Determination of the fluidity of plastics using capillary and slit-die rheometers' as well as HG/T 4300-2012 'Rubber. Measurement of rheological properties. Piston type capillary rheometer methods.' It is engineered specifically for assessing the shear rate of plastics and polymer materials along with the fluidity of melts under shear stress at specified temperatures. This includes determining the apparent viscosity of thermoplastics with precision and reliability.
2. This advanced rheometer is an intelligent, computer-controlled device capable of operating under a variety of conditions such as constant pressure, constant speed, and constant temperature. It efficiently works across diverse heating rates, temperatures, and shear rates. The sophisticated software intuitively sets parameters like pressure, temperature, and speed tailored to various plastics and die diameters, automatically plotting curves, and preserving and printing data seamlessly for your convenience.
3. Customization is our hallmark. We offer customization of different specifications-whether low temperature types, high temperature types, varying pressures, or diverse rod diameters, all tailored to meet your unique requirements.
Detailed Photos System composition Our system's architecture boasts a robust 'mouth'-shaped frame design ensuring maximum structural integrity. The streamlined exterior exudes beauty and elegance, combined with a cutting-edge technological feel. The transmission system features a precision ball screw of Taiwanese brand, delivering dual kinetic energy movement for seamless, no-shift performance during testing, ensuring stability and accurate results.The speed control system utilizes an advanced AC servo system, providing meticulous control over displacement and pressure, ensuring precision and excellence in testing.e. The heating unit is equipped with spiral heating wires ensuring uniform temperature distribution across the barrel, while the entire furnace body can be effortlessly moved for easy cleaning post-experiment. Our high-tech measurement system, enhanced by wireless remote control capabilities, simplifies preloading. The intuitive software interface allows you to set test modes and parameters easily, while also displaying real-time curves and results for comprehensive analysis.
Product Parameters

Temperature range	Room temperature~400ºC	Heating rate	1-10ºC/min,Continuously adjustable, and rapid heating
Temperature measurement display accuracy	0.1ºC	Pressure range	1-100MPa±0.5%
Maximum driving force	10KN ,20KN(Can be customized according to customer requirements)	Pressure measurement accuracy	±0.5%FS
Pressure resolution	0.1Mpa	Velocity range	0.01-500mm/min
Deformation measurement accuracy	±0.5%FS	Plug diameter	φ12 mm(Can be customized according to customer requirements)
Plug area	113.04mm2	Discharge die specification	Discharge die specification
Discharge die material	Tungsten carbide	Power supply	Power supply

Certifications
Company Profile Changchun Intelligent Instrument Equipment Co., Ltd. stands as a pillar of technology-driven innovation, integrating R&D, production, sales, and dedicated after-sales service. Established in 1989, with a rich legacy spanning 35 years, we proudly position ourselves among China's pioneers in testing machine development and production. Our expertise lies in the R&D and manufacturing of optomechanical and electrical integrated testing instruments, analytical devices, and automotive parts testing machinery. Our commitment to excellence is further emphasized by our ISO9001 international quality system certification.
As a recognized high-tech enterprise, we continually embrace advanced design philosophies and leverage our unique design capabilities. Meeting national and international standards, as well as German, American, and Japanese benchmarks, we have successfully developed over ten types of test instruments, analytical equipment, and automotive parts testing devices, showcasing our commitment to innovation and quality.
Exhibition photos

---
