| US$65,500.00 | 1 Piece (MOQ) |
| SPECIFICATION ITEM | KBD5280-I | |||||
| Injection unit | Unit | A | B | C | D | |
| SCREW DIA | mm | 75 | 80 | 85 | 90 | |
| SHOT VOLUME (THEORETICAL) | cm3 | 1727 | 1965 | 2219 | 2487 | |
| INJECTION WEIGHT(PS) | g | 1572 | 1788 | 2019 | 2264 | |
| INJECTION PRESSURE | Mpa | 191 | 168 | 148 | 132 | |
| SCREW SPEED | rpm | 0-110 | ||||
| | CLAMPING UNIT | |||||
| CLAMPING FORCE | KN | 5280 | ||||
| TOGGLE STROKE | mm | 770 | ||||
| SPACE BETWEEN TIE BARS | mm | 820*780 | ||||
| MAX.MOLD HEIGHT | mm | 810 | ||||
| Min.MOLD HEIGHT | mm | 330 | ||||
| EJECTOR STROKE | mm | 200 | ||||
| EJECTOR TONNAGE | KN | 150 | ||||
| OTHERS | | |||||
| PUMP MOTER POWER | Kw | 55 | ||||
| HEATING POWER | Kw | 29 | ||||
| MACHINE DIMENSION(L*W*H) | m | 8.5*2.2*2.8 | ||||
| MACHINE WEIGHT | T | 26 | ||||
