Water Hardness Meter Online Water Hardness Sensor Meter

Product Description

Product Description Calcium and magnesium ion detectors are widely used in waterworks, power plants, boiler water, hospitals, sewage treatment, chemical industry, etc. It is designed for continuous testing of hardness values in liquids.
Specification

Technical Parameters
Measuring Range:Water hardness 0-10000 mg/L(ppm),Temperature 0~60ºC		Selective units: mg/L,mmol/L,mmol/L(Boiler) =mmol/L(B) (Specified unit for industrial boiler water)
Resolution: 0.01mg/L, 0.1ºC		Accuracy : ±3%, ±0.5ºC
Automatic or manual temperature compensation function: 0~60ºC.		Control interface:Two groups of ON/OFF relay, divided into 2 points of high and low for alert control.
Analog output : 4~20mA		Relay:the relay lag value can be set freely. Relay load: 3A 220VAC/24VDC
Operating conditions:environmental temperature of 0~60ºC, relative humidity ≤90%		Working voltage: 220VAC10%,50/60Hz.
Dimention :96X105×168 mm		Hole size:92×92mm
Weight:0.9Kg		Protection Grade:IP65 (waterproof, dust-proof and damp-proof)

Main Features

Advanced water hardness ion-selective electrode technology (ISE) with high sensitivity, fast response and high stability. Easy to maintain.

Multi-parameters showed at the same time:Water hardness value, temperature, output current, and alarm of range ability etc.

Protection Grade:IP65 (waterproof, dust-proof and damp-proof).

Digital LCD display and English display interface.

(Optional) Communication function:with RS - 485 communication interface (MODBUS protocol compatible) .The corresponding hardness data of 4 ~ 20 mA can be set freely.

Analog output : 4~20mA

The relay lag value can be set freely to avoid frequent operation of relay.

Watchdog:make sure the meter dose not go dead.

The main components imported from foreign famous brand.

Power off protection>10 years.

ABS plastic casing (waterproof, dust-proof and damp-proof).

Product Display
Company Profile
Exhibition
Packaging & Shipping
FAQ 1.Q: How long is the delivery?
-- Mostly within 10days
2.Q:Can I get a sample?
-- Sure, contact our sales please
3.Q:What is your MOQ?
-- 1pcs
4.Q: How about warranty time?
-- 12-18month
5.Q: How can I visit your factory?
-- Fly to Xian Yang air port, it's our pleasure to pick you up.
6.Q:How do you control your quality ?
-- We have EPR system .we control from parts, process, testing, packing ,retesting.
Every Sensor will be tested two times before reach you, after that sport test for the third time. Make sure about the quantity.

---
