Product Details
Product Description
Product Description
Material: stainless steel 304, 304L, 304HC, 316, 316L, 321,430 or as per your request.
Application: The filter has been widely used in transformer oil, turbine oil, hydraulic oil, aviation kerosene, petroleum, chemical, power plant, coal carbon, mining, pharmaceutical, food, and engineering industries.
Customers can also avail customized sintered bronze filter cartridges, which are used mainly for liquid oxygen, compressed air and silencing with a filtration efficiency of 5 to 50 micron.
Advantage: 1. Strength: As the fourth and fifth layers do support, with high mechanical strength and compressive strength.
2. Easy to clean: As a result of the surface of the filter material, having means for cleaning characteristics, especially suitable for backwashing.
3. Easy processing: suitable for cutting, bending, stamping, drawing, welding and other processes.
4. High temperature: 480 °Ccan withstand high temperatures.
5. Corrosion resistance: As a result of SUS316L, 304 materials, the corrosion resistance.
6. Filtration: Filtration range of 1μm-200μm, has a reliable filter performance.
7. Stability: Because there are two layers to do to protect the screen, plus solid melting diffusion sintering process which makes filters is not easy to deform.
Specifications:
Filtering
Level
| Filtration
Precision
um
| Maximum
Hole
Diameter um
| Permeability
Coefficient
10~12㎡
| Permeability
M3/h.㎡.kpa
| Thickness
mm
| Compression
Strength
Mpa/cm2
| Bubbling
Pressure
Kpa
|
S9
| 0.2
| 2.5
|
| 1
| 0.6~10
| 3.0
|
|
S8
| 0.5
| 4
|
| 3
| 0.6~10
| 3.0
|
|
S7
| 1.5
| 6
|
| 5
| 0.6~10
| 3.0
|
|
S6
| 2.5
| 10
| 0.09
| 10
| 0.6~10
| 3.0
| 9.16
|
S5
| 5
| 15
| 0.23
| 40
| 0.6~10
| 3.0
| 6.1
|
8
| 20
| 0.91
| 80
| 0.6~10
| 3.0
| 4.6
|
S4
| 10
| 30
| 1.81
| 160
| 0.6~10
| 3.0
| 2.6
|
S3
| 28
| 60
| 3.82
| 350
| 0.6~10
| 3.0
| 1.8
|
35
| 80
| 7.29
| 500
| 0.6~10
| 3.0
| 1.4
|
S2
| 40
| 100
| 9.43
| 700
| 0.6~10
| 3.0
| 1.1
|
S1
| 65
| 160
| 15.1
| 1000
| 0.6~10
| 3.0
| 0.66
|
>>
