2000-2200MHz 8dBi Fiberglass 360 Degree Omni Directional Spring FRP Antenna

Product Description

Product Description
This is an Omni Spring Antenna designed for broadcast applications and suitable for mobile usage with vertical polarisation and flexible wideband omni antenna
Product Parameters

Performance of electricity index
model	AATBLG1820V8TF
Frequency Range (MHz)	1800-2000
Bandwidth (MHz)	200
gain (dBi)	8
radiation direction	360 omnidirectional
Polarization mode	perpendicular
voltage standing-wave ratio	≤2
input impedence (Ω)	50
maximum power (W)	100

mechanical behavior
Port	N female
Antenna length (mm)	φ32×850
Antenna weight (kg)	1.5
Cover material	Fiberglass (matte black)
working temperature (ºC)	-40~85
Ultimate wind speed (m/s)	60

---
